B855 Century Pool Spa Pump Motor 2HP 3450RPM 56Y ODP 230Volt 1 Phase CCWPE 10.0 AMPS

It is important to know that pool pump motors are not manufactured by the pump manufacturer; the motor will usually be manufactured by AO Smith, Magnetek or Centurion. Your pump's motor should have a label or faceplate on it which includes the information you need to replace your pump motor. The most important categories to note will be the horsepower (hp), motor frame (fr), voltage and service factor (sf). Some labels will provide you with a model number and it will usually be listed as CR or CAT. A.O. Smith Part Numbers: B855 2 HP - Up Rated Service Factor: 1.10 56Y Frame 230V 10 amps Square Flange (Face) Threaded Shaft Capacitor start All copper windings Automatic thermal protection Stainless steel threaded shaft Sealed ball bearings Cross Reference: R0479304, A0104700, 177897, 182115, 193268, B694, 1103675400, SQ120U, 8-177897-22, 10-177897-22, 7-177897-22 When replacing your pool pump motor you should always replace the shaft seal as well. The shaft seal is a 2 part piece made of rubber, metal and ceramic and keeps water from entering the pump motor. It is located near the impeller at the end of the motor shaft. Shaft seals vary between pumps so be sure to order the appropriate shaft seal for your pump.?

This single-compartment, permanent split capacitor motor can be used as an equivalent replacement for most popular pool and spa manufacturers' pumps. Must equal or exceed service factor and HP for proper replacement. Auto thermal protection helps protect against damage caused by overheating. Ball bearings. UL Recognized and CSA Certified.<br /><br /> Item: Pool and Spa Pump Motor<br /> Motor Application: Pump<br /> Motor Sub Application: Pool and Spa Pump<br /> Motor Design: Permanent Split Capacitor<br /> Motor Enclosure Design: Open Dripproof<br /> HP: 2<br /> Nameplate RPM: 3450<br /> Frame: 56Y<br /> Motor Shaft Rotation: CCWSE<br /> Voltage: 230<br /> Full Load Amps: 10.0<br /> Phase: 1<br /> Hz: 60<br /> Motor Mounting Type: Face<br /> Motor Bearings: Ball<br /> Finish: Black<br /> Motor Flange Material: Aluminum<br /> Shaft: Threaded 1/2-20 UNF-2A RH<br /> Shaft Material: 303 Stainless Steel<br /> Motor Thermal Protection: Auto<br /> Motor Service Factor: 1.10<br /> Ambient Temperature: 50 Degrees C<br /> Shaft Dia.: 5/8"<br /> Shaft Length: 7/16"<br /> Ins. Class: B<br /> RPM Range: 3001-3600<br /> Motor Efficiency Group: Standard Efficient<br /> Standards: UL Recognized (E14663), CSA Certified (LR642)

When your old pool pump motor calls it quit, have a replacement A.O. Smith 2-HP 3450 RPM Single-Speed Pool Pump Motor ready to swap in so you can get back enjoying your relaxing day on the water. This 2-horsepower up-rated replacement motor for above and in-ground swimming pool pumps has a threaded shaft and fits most pumps that require a square flange motor. It operates on 230-volts and has a 3450 RPM. The motor features a 1.1 service factor, an automatic surge protector, capacitor start, and an open drip-proof housing for cooler operation. With a comprehensive line of electric motors for commercial, industrial, and residential pump and general purpose applications, century is a highly recognized brand in the leisure water industry for its breadth of product offering, quality, and reliability.
