BG848A A.O. Smith Guardian Motor

BG848A Single Speed Guardian Pool Motor 1 HP NOTE: Image is of a C-face type, actual is a square flange HP - 1 RPM - 3450 Volts - 230/115 Max Amps - 8.0/16.0 Service Factor - 1.65 Frame - 56Y Shaft - Threaded Approx. "AG" - 10-1/4 Centurion Square Flange Applications: A.O Smith Guardian motors comply with requirements for safety vacuum release systems in the Virginia Graeme Baker Pool and Spa Safety Act of 2007. Guardian motors pass ASME A112.19.17 SVRS standard or ASTM standard F2387. Guardian motors will not prevent evisceration, hair, object, or partial limb entrapment and is designed for suction lift applications. Features: -Easy to Install -Auto-Reset -Auto-Calibration -Ball Bearing -Economical -60HZ -Stainless Steel Shaft -Nerve Center (lighting sequence) -Single-Speed -Single Phase -Run/Restart/Rest/Bypass Mode -Tamper-Resistant Housing -Compatible with all flow rates Also: --Facilitates no main drain pool designs in place of an equalizer line. Guardian motors shut off the motor/pump when the water level drops below the skimmer. --Reduces Pump, motor and seal damage --Shut off motor/pump if any of the following conditions occur: Dry, blocked or jammed pump conditions; locked rotor, loss of prime, or abnormal voltage variations --Detect clogged or blocked filters and shuts down the pump
