Evaporative Cooler Motor, Single Phase, Motor Design Split-Phase, 1/3 HP, Nameplate RPM 1,725, No. of Speeds 1, Voltage 115V AC, 6.5 Full Load Amps, 56Z Frame, 60 Hz, Usable @ 208V No, Usable @ 200V No, Motor Service Factor 1, Motor Thermal Protection Auto, Ins. Class B, Max. Ambient Temp. 40 Degrees C, Motor Shaft Rotation CW/CCW, Motor Enclosure Design Open Dripproof, Motor Mounting Type Cradle Base, Motor Mounting Position All Angle, Shaft Length 1 1/2 in, Shaft Dia. 1/2 in, Finish Varnish

Split-phase evaporative cooler AC motors are single phase with a lower starting torque for softer startup where the cooling fan must gradually come up to speed after startup. This listing is for each. Technical Specification Item Evaporative Cooler Motor Motor Application HVAC/R Motor Sub Application Evaporator Cooler Phase Single Motor Design Split-Phase HP 1/3 Nameplate RPM 1, 725 No. of Speeds 1 Voltage 115V AC Full Load Amps 6.5 Frame 56Z Hz 60 Usable @ 208V No Usable @ 200V No Motor Service Factor 1 Motor Thermal Protection Auto Ins. Class B Max. Ambient Temp. 40 Degrees C Motor Shaft Rotation CW/CCW Motor Enclosure Design Open Dripproof Motor Mounting Type Cradle Base Motor Mounting Position All Angle Shaft Length 1 1/2 in Shaft Dia. 1/2 in Finish Varnish Motor Bearings Ball Overall Length 9 7/16 in Length Less Shaft 7 15/16 in Ring to Ring Center 7 7/16 in Features Moisture Resistant Resilient Ring Dia. 2 1/2 in Motor Efficiency Group Standard Efficient Includes Hardware, Switch Parts Standards CSA, UL

' Evaporative Cooler Motor, Motor Design Split-Phase, Motor Enclosure Design Open Dripproof, HP 1/3, Nameplate RPM 1725, 56Z Frame, Voltage 115, 60 Hz, 1 Phase, 6.5 Full Load Amps, Motor Mounting Type Cradle Base, Motor Thermal Protection Auto, Ins. Class B, Motor Service Factor 1.00, Motor Bearings Ball, Ambient Temperature 40C, Max. Ambient Temp. 40 Degrees C, Motor Shaft Rotation CW/CCW, Length Less Shaft 7-15/16 In., Overall Length 9-7/16 In., Shaft Dia. 1/2 In., Shaft Length 1-1/2 In. '
