The DisplayPort 1.2a 1?2 Hub, MST is a device that allows you to extend different DisplayPort 1.2a content from one DisplayPort connector to two monitors. The hub supports video resolutions up to 4K and PCM Audio up to 7.1-Channel and up to 192 kHz sampling rate, and supports Multi-Stream Transport (MST) of up to eight streams</p>

The DisplayPort 1.2a 1×2 Hub, MST is a device that allows you to extend different DisplayPort 1.2a content from one DisplayPort connector to two monitors. The hub supports video resolutions up to 4K and PCM Audio up to 7.1-Channel and up to 192 kHz sampling rate, and supports Multi-Stream Transport (MST) of up to eight streams Specifications: Environment: DisplayPort 1.2a Device Targeted: Installation of DisplayPort or Mini DisplayPort output source equipment with DisplayPort input monitors Transmission: Transparent to the user. Video Bandwidth: 21.6 Gbps (5.4Gbps per lane) Signals: DisplayPort 1.2a & Dual mode DisplayPort protocol Transport: Supports Multi-Stream Transport (MST) of up to eight streams Resolution: Up to 3840 X 2160 @ 60 FPS HDCP: Revision 1.4 compliant. Audio: LPCM 7.1CH, Dolby TrueHD and DTS-HD Master Audio Connectors: Three DisplayPort connectors, One PSU connector Cabling Requirement: Input port : 1x Standard DisplayPort Cable; Output port : 2x Standard DisplayPort Cables (Select appropriate cable length for video resolution selected) LEDs: Input & Output Link: Blue Power Supply: 5VDC, 2A Temperature Operating: 32° to 104°F; Storage: -4° to 185°F Humidity: Maximum 90% (non-condensing) Enclosure: Black metal enclosure Dimensions: 4.33” x 2.95” x 1.00” Weight: 0.55lbs Compliance: Regulatory: FCC, CE, RoHS

The DisplayPort 12A 1 2 Hub MST is a device that allows you to extend different DisplayPort 12A content from one DisplayPort connector to two monitors The hub supports video resolutions up to 4K and PCM Audio up to 71Channel and up to 192 kHz sampling rate and supports MultiStream Transport MST of up to eight streams Features. Extend different displayport 12a content from one displayport connector to two monitors. Supports data rate of 54 gbps per lane with a total of 216 gbps link rate. Hdmi link rate 32 gbpsdata pair. Supports dual mode displayport. 4k at 60hz 24 bitspixel in dp 12a configuration. 1080p at 240hz 24 bitspixel. Supports multistream transport mst of up to eight streamsSpecifications. Size 1 x 2. Environment DisplayPort 12a. Device Targeted Installation of DisplayPort or Mini DisplayPort output source equipment with DisplayPort input monitors. Transmission Transparent to the user. Video Bandwidth 216 Gbps 54Gbps per lane. Signals DisplayPort 12a Dual mode DisplayPort protocol. Transport Supports MultiStream Transport MST of up to eight streams. HDCP Revision 14 compliant. Audio LPCM 71CH Dolby TrueHD and DTSHD Master Audio. Cabling Requirement Input port 1x Standard DisplayPort Cable Output port 2x Standard DisplayPort Cables Select appropriate cable length for video resolution selected. Temperature Operating 32 to 104F Storage 4 to 185F. Humidity Maximum 90 Percent noncondensing. Enclosure Black metal enclosure. Compliance Regulatory FCC CE RoHS. Warranty 2 s. Dimensions 433 x 295 x 100 . Weight 15 lbs
