NACHI Ball Screw Support Bearing 40TAB09UP4, Single, Flush Ground, 40MM Bore, 90MM OD

Nachi . 40TAB09UP4

Gallery

Attributes

Brand name, Manufacturer name, ManufacturerNachi
CategoryL1Motors & Power Transmission
CategoryL2Bearings
CategoryL3Angular Contact Bearings
KnownMan, Extra Product NameNACHI Ball Screw Support Bearing 40TAB09UP4, Single, Flush Ground, 40MM Bore, 90MM OD
extendedLead15
extendedQty-2
jsonUrlData30937172
moq, multiple, tierMinQty11
MPN40TAB09UP4
qtyInStockShips in 5 Business Days
SKUWBB937172
snippet<b>Features</b><br><br><ul style="margin-top:0px; padding-top: 5px; padding-bottom: 5px;"><li>These bearings are designed to support ball screws that are used as actuators of high precision and high speed machines</li><li>Their stiffness is much greater than conventional angular contact ball bearings as these have a greater number of balls</li><li>These bearings are supplied with a pre-set preload to eliminate complicated adjustment and torque measurement</li><li>Flush ground bearings (suffix DU or U) can be used in DB (back to back), DF (face to face) or DT (tandem) assembly</li></ul><b>NOTE - Load Ratings</b><br><br>When single flush ground bearing (suffix U) is assembled in duplex and axial load is applied to 2 rows or 3 rows, load rating listed is to be multiplied by 1.62 or 2.16 respectively for Dynamic and multiplied by 2 or 3 respectively for Axial Limiting Load.<br><br>
tierPrice1284.95

Distributor offers

SellerSKUMOQIn stockMultiplePrices
Global IndustrialWBB9371721Ships in 5 Business Days11 @ $284.95
MRO Supply208819111 @ $280.00
Lily Bearing40TAB09UP41-211 @ $317.70
ZoroG1386976111 @ $279.89
