SunSource | 70160-RAE-03 EATON Industrial Hydraulics | SunSource.com

None . 70160-RAE-03

Gallery

Attributes

Brand name, Manufacturer name, Manufacturer, Attribute04, Attribute40, Attribute41None
Attribute00Mining Machinery, Dump Trucks Lift, Agriculture Tractore , Railroad Equipments Etc.
Attribute01, Attribute10, Attribute43Single
Attribute02With Diameter 18.75 [.750] Taper .125-1, Keyway 4.78 X 19.8 [.188 X .78] And .3125-24 UNF-2B, 12.2 [.48] Minimum Full Thread (Key Included); 113 [4.45] From Unit Centerline To Control Shaft End
Attribute03C
Attribute0520.3 cubic centimetre per revolution
Attribute06http://wcm-prod-cs.etn.com/ecm/groups/public/@pub/@eaton/@hyd/documents/content/a-290-002.pdf
Attribute07http://wcm-prod-cs.etn.com/ecm/groups/public/@pub/@eaton/@hyd/documents/content/a-292-035.pdf
Attribute08http://wcm-prod-cs.etn.com/ecm/groups/public/@pub/@eaton/@hyd/documents/content/a-433-036_port_installation.pdf
Attribute09http://wcm-prod-cs.etn.com/ecm/groups/public/@pub/@eaton/@hyd/documents/content/a-448-021_shaft_install.pdf
Attribute11EAR99
Attribute1264.3 litre per minute
Attribute13Cast Iron
Attribute14Mobile - CC Piston Pumps
Attribute15, Attribute26Standard
Attribute1613 Tooth 16/32 Spline, Shaft Ext 41.1 [1.62]
Attribute17, Attribute18Opposite Sides
Attribute19Radial
Attribute201.0625-12 UN-2B SAE O-RING PORTS
Attribute2142 kilowatt
Attribute22119 newton metre
Attribute23, Attribute445076 psi
Attribute24ADB12R4ARB11FF1F0A00300A00000B0C
Attribute25Standard J744
Attribute27Black Per Spec 209-13B
Attribute285500 psi
Attribute29, Attribute366.53
Attribute30, Attribute32, Attribute37inch
Attribute319.95
Attribute3370160 Series
Attribute3421.00
Attribute35pound
Attribute383600 revolutions per minute
Attribute39Right
Attribute42Variable Displacement
AttributeKey00Application
AttributeKey01Configuration
AttributeKey02Control shaft
AttributeKey03Design code11
AttributeKey04Design type
AttributeKey05Displacement
AttributeKey06Documentlink 2d drawings 4
AttributeKey07Documentlink 2d drawings 5
AttributeKey08Documentlink 2d drawings 6
AttributeKey09Documentlink 2d drawings 7
AttributeKey10Drive shaft seal configuration
AttributeKey11Eccn
AttributeKey12Flow at rated speed and psi
AttributeKey13Housing material
AttributeKey14Icc2
AttributeKey15Identification
AttributeKey16Input shaft
AttributeKey17Main port location a
AttributeKey18Main port location b
AttributeKey19Main port orientation
AttributeKey20Main port s
AttributeKey21Maximum input power
AttributeKey22Maximum input torque
AttributeKey23Minimum working pressure
AttributeKey24Model Code
AttributeKey25Mounting flange location
AttributeKey26Mounting Type
AttributeKey27Paint
AttributeKey28Peak pressure rating
AttributeKey29Product height
AttributeKey30Product height uom
AttributeKey31Product length
AttributeKey32Product length uom
AttributeKey33Product trade name
AttributeKey34Product weight
AttributeKey35Product weight uom
AttributeKey36Product width
AttributeKey37Product width uom
AttributeKey38Rated speed max
AttributeKey39Shaft rotation
AttributeKey40Special features17
AttributeKey41Sub brand
AttributeKey42Type
AttributeKey43Unit type21
AttributeKey44Working pressure max
AttributeKey45Requires Quote
Extra Product NameSunSource | 70160-RAE-03 EATON Industrial Hydraulics | SunSource.com
jsonUrlDatac1445112-1787-49f2-93ec-ae2800087755
keywordsHYDRAULIC PUMP 70160-RAE-03
moq, multiple, tierMinQty11
MPN, SKU70160-RAE-03
qtyInStock, tierPrice10
snippet70160-RAE-03 EATON | Search our online catalog of Industrial Hydraulics. Start your quote online to connect with our team of technical experts for support.

Distributor offers

SellerSKUMOQIn stockMultiplePrices
sun-source.com70160-RAE-03111 @ $0.00
