Order YAZ36TC3890 by Burndy 25020439 Cu Terminal, 2 Hole, (Pack of 10 pcs) - US Mega Store

Burndy . YAZ36TC3890

Gallery

Attributes

Brand name, Manufacturer name, ManufacturerBurndy
CategoryL1Networking & Wiring
CategoryL2Wire Connectors
CategoryL3Burndy YAZ36TC3890
ConditionNEW
DimensionUnitinch
Extra Product NameOrder YAZ36TC3890 by Burndy 25020439 Cu Terminal, 2 Hole, (Pack of 10 pcs) - US Mega Store
diameter, length1.19
height3.99
height_AttribDimension - Height inch
length_AttribDimension - Outside Diameter inch
moq, multiple, tierMinQty1, Physical Attribute - Number of Holes1
MPN, SKUYAZ36TC3890
qtyInStock-2
qtySourceFieldMap
snippet<p><strong>Burndy, YAZ36TC3890, 25020439 Cu Terminal, 2 Hole </strong> </p>
tierPrice187.65
width1.74
width_AttribDimension - Pad Width inch
Color CodeGreen
Connector TypeTerminal
Die Index22;472
Feature - Barrel StyleSkived
Feature - Barrel TypeLong
Material, Conductor - MaterialCopper
PlatedY
Plating TypeTin - Electro Plated
TypeLong Barrel, Skive, Tin Plated
Dimension - B Length fraction2-11/16 in
Dimension - B Length inch2.69 in
Dimension - Bolt Hole Size inch, Dimension - Hole Size inch0.40 in
Dimension - Bolt Size fraction3/8
Dimension - Height inch3.99 in
Dimension - Hole Size mm10 mm
Dimension - L Length Overall mm46 mm
Dimension - Length Overall inch1.80 in
Dimension - N inch0.50 in
Dimension - Outside Diameter inch1.19 in
Dimension - Pad Width inch1.74 in
Dimension - Strip Length inch2-3/4
Dimension - Z inch0.52 in
Physical Attribute - Tongue Angle90 Degree
Rating - KVA35 kV
Rating - Minimum Voltage600
Voltage - Maximum35000
Conductor - Copper Str Size600 kcmil
Certification - CSA Approved, UL ListedYes
Certification - ETL, Certification - UL Recognized, Certification - cULusNo
Standards - RoHS Compliance StatusCM

Distributor offers

SellerSKUMOQIn stockMultiplePrices
usmegastore.comYAZ36TC38901-211 @ $87.65
