Dayton

Dayton . 71631616M

Gallery

Attributes

Brand name, Manufacturer name, Manufacturer, Extra Product NameDayton
DimensionUnitinch
GraingerSku5K004
UnitOfMeasureEA
Voltage115V AC
Weight4.95
WeightUnitlbs
cali_prop65_orglabel, cali_prop65_whtlabelFalse
countryOfOriginMX
height4.2
jsonUrlData924526ffbdad25e5923b
length4.6
moq, multiple, tierMinQty1, Number of Speeds, No of Speeds, Number of Shafts, Motor Service Factor1
MPN71631616M
qtyInStock471
qtyInStockOverride-2
SKUG2375965
tierPrice189.18
urlhttps://www.zoro.com/dayton-hvac-motor-120-hp-1550-rpm-115v-33-71631616m/i/G2375965/
width8.4
Nameplate RPM1,550 RPM
Motor Enclosure DesignTotally Enclosed Fan-Cooled
HP1/20
RPM Range1,501-1,600
Motor Mounting Type, MountingStud
ApplicationOEM and Replacement Use In A Wide Variety of Fan and Blower
Motor Thermal ProtectionAuto
ItemHVAC Motor
Duty, Duty CycleContinuous
Motor DesignShaded Pole
Motor ApplicationHVAC/R
StandardsCSA Certified, UL Recognized
Full Load Amps1.80
Max Ambient Temp40 Degrees C
Motor BearingsBall
Mounting Pattern2 x 2
Body Dia4 in
Frame3.3
PhaseSingle
Motor Sub ApplicationDirect Drive Fan/Blower
Ins ClassB
Mounting Stud Location4/Shaft End
Voltage Compatibility115/208-230V AC, 115/230V AC, 115V AC, 120/240V AC, 120V AC
Motor Shaft DesignFlat
Stud/Base Mtg Pattern, Mounting Stud Pattern2 in x 2 in
Shaft Dia5/16 in
Shaft Length2 1/4 in
Motor Shaft RotationCWSE
Length Less Shaft4 1/4 in
Cord Length12 in
Hz60 Hz
Capacitor Required, Usable @ 208V, Usable @ 200VNo
Motor Mounting PositionAll Angle
Country of Origin (subject to change)Mexico

Distributor offers

SellerSKUMOQIn stockMultiplePrices
ZoroG2375965147111 @ $89.18
Grainger5K00411
simsupply.comCU-354B303034116811 @ $94.96
simsupply.comZO-G237596514211 @ $103.55
