Dayton

Dayton . 71732487M

Gallery

Attributes

Brand name, Manufacturer name, Manufacturer, Extra Product NameDayton
DimensionUnitinch
GraingerSku498X31
UnitOfMeasureEA
Voltage115V AC
Weight2.2
WeightUnitlbs
cali_prop65_orglabel, cali_prop65_whtlabelFalse
countryOfOriginMX
height3.8
jsonUrlData924526ffbdad25e5923b
length6.7
moq, multiple, tierMinQty1, Number of Speeds, Number of Shafts, Motor Service Factor, No of Speeds1
MPN71732487M
qtyInStock38
qtyInStockOverride-2
SKUG3791333
tierPrice152.85
urlhttps://www.zoro.com/dayton-hvac-motor-170-hp-1550-nameplate-rpm-71732487m/i/G3791333/
width3.9
Nameplate RPM1,550 RPM
Motor Enclosure DesignTotally Enclosed Air-Over
HP1/70
RPM Range1,501-1,600
Motor Shaft RotationCCWSE
Motor Mounting TypeStud
Motor Shaft DesignFlat
Voltage Compatibility115/208-230V AC, 115/230V AC, 115V AC, 120/240V AC, 120V AC
Motor BearingsSleeve
Frame3.3
Mounting Pattern2-7/8
Full Load Amps0.60
Length Less Shaft2 1/8 in
Mounting Stud Location2/Both Ends
Max Ambient Temp40 Degrees C
PhaseSingle
Body Dia3 5/16 in
Capacitor Required, Usable @ 200V, Usable @ 208VNo
ApplicationHVAC/R
Stud/Base Mtg Pattern2-7/8 in
Shaft Length2 1/4 in
Plug TypeNone
Ins ClassB
Hz60 Hz
Motor ApplicationGeneral Application
Motor Sub ApplicationDirect Drive Fan/Blower
Shaft Dia1/4 in
Motor DesignShaded Pole
Duty, Duty CycleContinuous
ItemHVAC Motor
Motor Thermal ProtectionAuto
StandardsCSA Certified, UL Recognized
Mounting Stud Pattern2 7/8 in
Country of Origin (subject to change)Mexico

Distributor offers

SellerSKUMOQIn stockMultiplePrices
ZoroG379133313811 @ $52.85
Grainger498X3111
simsupply.comCU-3439385833311911 @ $59.36
simsupply.comZO-G379133312311 @ $61.42
