OD9225-24HBIP69K Orion Fans | Fans, Thermal Management | DigiKey
Fan Tubeaxial 24VDC Square - 92mm L x 92mm H Ball 50.0 CFM (1.40m?/min) 2 Wire Leads
Gallery
Attributes
| Brand name, Manufacturer name, Manufacturer, Mfr | Orion Fans |
|---|---|
| CategoryL1, Category | Fans, Thermal Management |
| CategoryL2 | Fans |
| CategoryL3 | DC Brushless Fans (BLDC) |
| DimensionUnit | mm |
| Extra Product Name | OD9225-24HBIP69K Orion Fans | Fans, Thermal Management | DigiKey |
| atoms, moq, multiple, tierMinQty1 | 1 |
| extraShipping | 0 |
| MPN, Manufacturer Product Number | OD9225-24HBIP69K |
| packaging, Package | Box |
| qtyInStock | 295 |
| SKU | 12756306 |
| snippet, Detailed Description | Fan Tubeaxial 24VDC Square - 92mm L x 92mm H Ball 50.0 CFM (1.40m?/min) 2 Wire Leads |
| tierMinQty2 | 10 |
| tierMinQty3 | 25 |
| tierMinQty4 | 50 |
| tierMinQty5 | 100 |
| tierMinQty6 | 250 |
| tierMinQty7 | 500 |
| tierPrice1 | 22.34000 |
| tierPrice2 | 20.40600 |
| tierPrice3 | 19.63080 |
| tierPrice4 | 18.33920 |
| tierPrice5 | 16.91860 |
| tierPrice6 | 16.66036 |
| tierPrice7 | 16.53120 |
| width | 25.0 |
| width_Attrib | Width |
| Digi-Key Part Number | 1053-OD9225-24HBIP69K-ND |
| Description | FAN AXIAL 92X25MM 24VDC WIRE |
| Manufacturer Standard Lead Time | 19 Weeks |
| Series | OD9225-IP69K |
| Product Status | Active |
| Voltage - Rated | 24VDC |
| Size / Dimension | Square - 92mm L x 92mm H |
| Width | 25.00mm |
| Air Flow | 50.0 CFM (1.40m?/min) |
| Static Pressure | 0.240 in H2O (59.8 Pa) |
| Bearing Type | Ball |
| Fan Type | Tubeaxial |
| Features | Auto Restart |
| Noise | 35.0dB(A) |
| Power (Watts) | 3.5 W |
| RPM | 2900 RPM |
| Termination | 2 Wire Leads |
| Ingress Protection | IP69K - Dust Tight, Water Resistant, Waterproof |
| Operating Temperature | -4 ~ 149?F (-20 ~ 65?C) |
| Approval Agency | CE, cURus, TUV, UR |
| Current Rating (Amps) | 0.180A |
| Voltage Range | - |
| Material - Frame, Material - Blade | Polybutylene Terephthalate (PBT) |
| Lifetime @ Temp | 70000 Hrs @ 40?C |
| Base Product Number | OD9225 |
Distributor offers
| Seller | SKU | MOQ | In stock | Multiple | Prices |
|---|---|---|---|---|---|
| Digi-Key | 12756306 | 1 | 295 | 1 | 1 @ $22.34, 10 @ $20.41, 25 @ $19.63, 50 @ $18.34, 100 @ $16.92, 250 @ $16.66, 500 @ $16.53 |
 Newark | 45AJ0138 | 20 | 20 | 10 @ $21.78, 25 @ $20.42, 50 @ $19.07, 100 @ $17.72 | |
| 10142091 | 1 | 1 | 1 @ $20.45 | ||
| us.rs-online.com | 72127375 | 1 | 20 | 1 | 1 @ $21.83, 10 @ $19.93, 25 @ $19.18, 50 @ $17.92, 100 @ $16.53, 250 @ $16.28 |
 Newark | 83AK2448 | 1 | 4 | 1 | 1 @ $22.87, 5 @ $21.27, 10 @ $20.53, 25 @ $19.79, 50 @ $18.69, 100 @ $16.72 |
