IXYS IXFH320N10T2 | Transistor: N-MOSFET; unipolar; 100V; 320A; 1000W; TO247-3; 98n
Gallery
Attributes
| Brand name, Manufacturer name, Manufacturer, Mfr | IXYS |
|---|---|
| Extra Product Name | IXFH320N10T2 IXYS | Discrete Semiconductor Products | DigiKey |
| atoms, minimum, moq, multiple | 1 |
| MPN | IXFH320N10T2 |
| qtyInStock | 1912 |
| SKU | IXFH320N10T2-ND |
| Part Status | Active |
| FET Type | N-Channel |
| Technology | MOSFET (Metal Oxide) |
| Current - Continuous Drain (Id) @ 25?C | 320A (Tc) |
| Drive Voltage (Max Rds On, Min Rds On) | 10V |
| Rds On (Max) @ Id, Vgs | 3.5mOhm @ 100A, 10V |
| Vgs(th) (Max) @ Id | 4V @ 250?A |
| Vgs (Max) | ?20V |
| FET Feature | - |
| Power Dissipation (Max) | 1000W (Tc) |
| Operating Temperature | -55?C ~ 175?C (TJ) |
| Mounting Type | Through Hole |
| Supplier Device Package | TO-247AD (IXFH) |
| Package / Case | TO-247-3 |
| Drain to Source Voltage (Vdss) | 100 V |
| Gate Charge (Qg) (Max) @ Vgs | 430 nC @ 10 V |
| Input Capacitance (Ciss) (Max) @ Vds | 26000 pF @ 25 V |
Distributor offers
| Seller | SKU | MOQ | In stock | Multiple | Prices |
|---|---|---|---|---|---|
| IXFH320N10T2-ND | 1 | 1912 | 1 | ||
| Win Source | IXFH320N10T2 | 1 | 65000 | 1 | |
 swatee.com | IXFH320N10T2 | 1 | 75 | 1 | 1 @ $21.58 |
| IXFH320N10T2 | 1 | 1 | 1 @ $14.69, 3 @ $13.13, 10 @ $11.80, 30 @ $10.97 | ||
| B00HKZ36QS | 1 | 1 | |||
| 2356165 | 1 | 1 | 1 @ $15.47, 10 @ $14.22, 100 @ $12.01, 500 @ $10.68, 1000 @ $9.80 |
