CYRF89235-40LTXC Cypress Semiconductor Corp | RF/IF and RFID | DigiKey
IC RF TxRx + MCU General ISM \u003e 1GHz 2.4GHz 40-VFQFN Exposed Pad
Gallery
Attributes
| Brand name, Manufacturer name, Mfr | Cypress Semiconductor Corp |
|---|---|
| Manufacturer | Cypress Semiconductor Corp CYPRESS SEMICONDUCTOR Cypress Semiconductor |
| Extra Product Name | CYRF89235-40LTXC Cypress Semiconductor Corp | RF/IF and RFID | DigiKey |
| atoms, moq, multiple, tierMinQty1 | 1 |
| extraShipping, qtyInStock | 0 |
| MPN, Part Number, Model, PartNumber | CYRF89235-40LTXC |
| SKU | 12616239 |
| tierPrice1 | 1.04000 |
| Product Group | BISS |
| Category | RF/IF and RFID |
| Series | PRoC? |
| Package | Tray |
| Part Status | Obsolete |
| Type | TxRx + MCU |
| RF Family/Standard | General ISM > 1GHz |
| Protocol | - |
| Modulation | GFSK |
| Frequency | 2.4GHz |
| Data Rate (Max) | 1Mbps |
| Power - Output | 1dBm |
| Sensitivity | -87dBm |
| Memory Size | 32kB Flash, 2kB SRAM |
| Serial Interfaces | I?C, SPI, USB |
| GPIO | 13 |
| Voltage - Supply | 1.9V ~ 3.3V |
| Current - Receiving | 18mA |
| Current - Transmitting | 13.7mA ~ 18.5mA |
| Operating Temperature | 0?C ~ 70?C |
| Mounting Type | Surface Mount |
| Package / Case | 40-VFQFN Exposed Pad |
| Supplier Device Package | 40-QFN (6x6) |
| ASIN | B00DK85NJM |
| Asin | B00DK85NJM B00LQQXDE2 B00LQQXFPO B00LQQXI4C B00LQQXLBM B00M2DIXCA B00M2DIZUA |
| Brand | CYPRESS SEMICONDUCTOR |
| Case, PackageQuantity | 1 10 100 5 50 |
| Cat | Industrial & Scientific |
| CatId | 16310091 |
| CatTree | 16310091 16310161 306506011 306831011 306842011 |
| CatalogNumberList | MS 727-CYRF89235-40LTXC X10 MS 727-CYRF89235-40LTXC X5 NW 69W1603 X10 NW 69W1603 X100 NW 69W1603 X5 NW 69W1603 X50 |
| Feature | Manufacturer: Cypress Semiconductor Product Category: RF Transceiver RoHS: Frequency Range: 2.4 GHz Maximum Data Rate: 1 Mbps Modulation Format: GFSK Type: ISM Operating Supply Voltage: 3.15 V to 3.45 V Maximum Operating Temperature: + 70 C Interface Type: GPIO,I2C, SPI Package / Case: QFN-40 Packaging: Tray Brand: Cypress Semiconductor Minimum Operating Temperature: 0 C Price For: Each Frequency Max: 2.4GHz Modulation Type: GFSK Data Rate: 1Mbps RF IC Case Style: QFN No. of Pins: 40 Supply Voltage Min: 3.15V Supply Voltage Max: 3.45V Operating Temperature Min: 0\xb0C RoHS Compliant: Yes |
| Height, Width | 75 |
| IsDeadAsin | True |
| Label, Man, Publisher, Studio | CYPRESS SEMICONDUCTOR Cypress Semiconductor |
| ProductGroup | BISS BISS Basic |
| ProductTypeName | ELECTRONIC_COMPONENT |
| Title | CYPRESS SEMICONDUCTOR CYRF89235-40LTXC RF TRANSCEIVER, 2.4GHZ, QFN-40 (10 pieces) CYPRESS SEMICONDUCTOR CYRF89235-40LTXC RF TRANSCEIVER, 2.4GHZ, QFN-40 (100 pieces) CYPRESS SEMICONDUCTOR CYRF89235-40LTXC RF TRANSCEIVER, 2.4GHZ, QFN-40 (5 pieces) CYPRESS SEMICONDUCTOR CYRF89235-40LTXC RF TRANSCEIVER, 2.4GHZ, QFN-40 (50 pieces) RF Transceiver Wireless Capacitive Touch (1 piece) RF Transceiver Wireless Capacitive Touch (10 pieces) RF Transceiver Wireless Capacitive Touch (5 pieces) |
| URL | https://m.media-amazon.com/images/I/41r6IOsn67L._SL75_.jpg |
| Units | pixels pounds |
| Weight | 0.000625 |
Distributor offers
| Seller | SKU | MOQ | In stock | Multiple | Prices |
|---|---|---|---|---|---|
| Digi-Key | 12616239 | 1 | 1 | 1 @ $1.04 | |
| Hotenda | H3898535 | 1 | 1 | 1 @ $4.73, 10 @ $4.22, 25 @ $3.80, 100 @ $3.46, 490 @ $3.13, 980 @ $2.54 | |
 swatee.com | CYRF89235-40LTXC | 1 | 28 | 1 | 1 @ $7.01 |
| Digi-Key | 3992864 | 1 | 1 | 1 @ $1.04 | |
| Digi-Key | 9644496 | 1 | 1 | 1 @ $1.04 |
