Pillow Block, 0.750 In Bore, 1.625 In L

Dayton . 2CNL9

Gallery

Attributes

Brand name, Manufacturer name, ManufacturerDayton
DimensionUnitinch
Extra Product NamePillow Block, 0.750 In Bore, 1.625 In L
WeightUnitlbs
extendedLead, moq, multiple, tierMinQty11
MPN2CNL9
qtyInStock-1
SKUG3381147
tierPrice118.45
urlhttps://www.zoro.com/i/G3381147
ItemLinear Pillow Block Bearing
Bore Dia (In )0.750
Flange Dia (In ), Overall Height (In )2.188
Flange Dia (mm), Dimension I, Dimension E (In ), Bore Dia (mm), Locking Type, Dimension B (In ), Max Pv, Retaining Ring, Dimension D (In ), Shaft Dia (In ), Static Load Capacity (N), Dimension A1 (In ), Steady State Speed - Intermittent Dry, Dimension V, Dimension F, Dimension P, Dimension E1 (In ), Dimension O, Slot Angle (Degrees), Dynamic Load Capacity (N), Mounting Hole (In ), Dimension N3, Slot Width (mm), Dimension C (In ), Overall Length (mm), Dimension E, Dimension A (In ), Agency Compliance, Mounting Hole Dia (mm), Dimension B, Dimension H (In ), Body Width (mm), Steady State Speed - Continuous Dry, Width, Dimension E2, Includes, Dimension A, Dimension N, Dimension N2, Bolt Size, Dimension S (In ), Dimension C, Dimension S, Mounting Bolt (In ), Dimension V (In ), Mounting Surface to Shaft Center (mm), Flange Thickness (mm), Overall Width (mm), Self-Alignment, Dimension A1, Dimension F1 (In ), Dimension G1 (In ), Dimension A2 (In ), Dimension H1 (In ), Dimension R, Dimension A2, Height, Overall Height (mm), Dimension N Dia (In ), Seal, Dimension d, Dimension H2, Dimension M (In ), Dimension G, Dimension G (In ), Accelerated Speed, Dimension F1, Barrel Dia (mm), Dimension F (In ), Dimension E1-
MaterialStainless Steel/Polymer Cage
Mounting Hole Dia (In )7/32
Dimension X0.219"
Bearing TypeBall Bushing
Temp Range (F)0 - 176
Overall Length (In )1.625
Flange Thickness (In )0.312
Dimension Z0.203"
TypeFlanged
Static Load Capacity (Lb )308
Dimension D1.250"
Dimension Dp1.718"
ColorSilver/Black
Mounting Hole Center (In )1215
Dynamic Load Capacity (Lb )194
FinishStandard Anodized
For Use WithLinear Motion Shafts
Body Width (In ), Barrel Dia (In ), Overall Width (In )1.250
Steady State Speed7 Feet/Second
Dimension Y0.344"
Mounting Hole Center (mm)30.900000000000002
Dimension K1.688"
Dimension L (In )1.625"

Distributor offers

SellerSKUMOQIn stockMultiplePrices
ZoroG33811471In Stock11 @ $18.45
