Zoro Select

Zoro Select . S-MS-6P-CB

Gallery

Attributes

Brand name, Manufacturer name, Manufacturer, Extra Product NameZoro Select
DimensionUnitinch
GraingerSku, MPNS-MS-6P-CB
UPCNone
UnitOfMeasureEA
Weight7.22
WeightUnitlbs
cali_prop65_orglabel, cali_prop65_whtlabelFalse
countryOfOriginCN
extendedLead11
extendedQty-2
height, length7.5
jsonUrlData924526ffbdad25e5923b
moq, multiple, tierMinQty1, Number of Wheels1
qtyInStock0
qtyInStockOverrideDrop Ship
SKUG9261633
tierPrice169.33
urlhttps://www.zoro.com/zoro-select-plte-caster-swvl-phenolic-6-900-lb-s-ms-6p-cb/i/G9261633/
width5.3
Caster Brake Included, Non-Marking, Caster Temp Range AvailableYes
Caster Load Rating RangeLight-Medium Duty
Caster Sub-TypeSwivel
Caster Wheel Shape, Tread ShapeStandard
Caster Wheel/Tread Material, Caster Core Material, Wheel Core Material, Wheel/Tread MaterialPhenolic
Load Rating900 lb
Overall Height7-1/2"
Wheel Dia6 in
Wheel Width2 in
Outside Bolt Hole Spacing4 1/8 in x 4 1/2 in
Caster Raceway, Swivel Raceway TypeDouble Ball
Frame FinishZinc Plated
Inside Bolt Hole Spacing4 in x 4 in
Caster Plate Size5" x 5-1/2"
Thread Guards, Extended LeadNo
Caster Brake TypePedal
Caster Swivel Lock Type, Swivel Lock TypeNo Lock Included
Caster Max Temp300 Degrees F
Wheel Color, Core ColorBlack
Mounting Bolt Dia3/8 in
ApplicationAll Purpose Industrial and Commercial Casters, Casters, Aerospace Tooling, Automotive Assembly Lines, Body Dolly Carts, Engine Dollies, Material Carts, Chassis Rack Carts
IncludesSpanner Bushing
Durometer90 Shore D
Replacement Wheel23EM59
Plate Caster Bolt Hole Pattern, Caster Plate Hole PatternB
Caster Frame MaterialSteel
Caster Plate Thickness1/4"
ItemPlte Caster
StandardsICWM
Caster Min Temp-50 Degrees F
Caster Wheel BearingsRoller
Caster Product GroupSwivel Caster with Brake
Mounting Plate Size5 in x 5 1/2 in
Load Rating RangeLight Medium
Country of Origin (subject to change)China

Distributor offers

SellerSKUMOQIn stockMultiplePrices
ZoroG9261633111 @ $69.33
ZoroG9446245111 @ $84.02
