DS18 ZR6.2D 6-1/2" Elite-Z DVC Subwoofer 2 Ohms Per Coil

. Part Number: 294-8064 by DS18.

DS18 . ZX6

Gallery

Attributes

Brand name, Manufacturer name, Manufacturer, BrandDS18
DimensionUnitinch
Extra Product NameDS18 ZR6.2D 6-1/2" Elite-Z DVC Subwoofer 2 Ohms Per Coil
UPC663593064820
Weight7.35
WeightUnitlbs
depth, length3.49
diameter, height, width6.75
height_Attrib, width_AttribOverall Outside Diameter
length_AttribDepth
moq, multiple1
MPN, ModelZX6
qtyInStockOnly 4 In Stock
SKU, Part Number294-8064
snippet. Part Number: 294-8064 by DS18.
Unit of MeasureEach
Nominal Diameter6-1/2"
Speaker Size4"
Power Handling (RMS)300 Watts
Power Handling (MAX)600 Watts
Impedance4?
Frequency Response38 to 200Hz
Sensitivity82dB 2.83V/1m
Voice Coil Diameter1.5"
Resonant Frequency (Fs)65Hz
DC Resistance (Re)3.6?
Mechanical Q (Qms)3.412
Electromagnetic Q (Qes)0.769
Total Q (Qts)0.627
Compliance Equivalent Volume (Vas)0.0936ft?
Mechanical Compliance of Suspension (Cms)0.108mm/N
BL Product (BL)5.37T?m
Diaphragm Mass Inc Airload (Mms)55.41g
Maximum Linear Excursion (Xmax)15mm
Surface Area of Cone (Sd)143cm?
Cone MaterialPaper-Treated Paper
Surround MaterialFoam
Voice Coil Wire MaterialCopper
Voice Coil FormerAluminum
Basket / Frame MaterialSteel
Magnet MaterialFerrite
Overall Outside Diameter6.75"
Baffle Cutout Diameter5.54"
Depth3.49"
# Mounting Holes4
Sealed Volume0.25ft?
Sealed F382Hz
Vented Volume0.45ft?
Vented F344.7Hz
