OMRON G2R-1E 24VDC | Relay: electromagnetic; SPDT; Ucoil: 24VDC; Icontacts max: 16A
OMRON G2R-1E 24VDC | Relay: electromagnetic; SPDT; Ucoil: 24VDC; Icontacts max: 16
Gallery
Attributes
| Brand name, Manufacturer name, Manufacturer | OMRON |
|---|---|
| CategoryL1 | Relays and Contactors |
| CategoryL2 | Relays |
| CategoryL3 | Electromagnetic Relays |
| CategoryL4 | Miniature Electromagnetic Relays |
| Extra Product Name | OMRON G2R-1E 24VDC | Relay: electromagnetic; SPDT; Ucoil: 24VDC; Icontacts max: 16A |
| atoms, moq, multiple | 1 |
| jsonUrlData | edacdb32e29149acc96f2325d5cd908b. |
| jsonUrlData2 | d055db9c8cff9fad37d2 |
| keywords | OMRON, G2R-1E 24VDC, G2R-1E-24VDC |
| MPN | G2R-1E 24VDC |
| qtyInStock | 0 |
| SKU | G2R-1E-24VDC |
| snippet | OMRON G2R-1E 24VDC | Relay: electromagnetic; SPDT; Ucoil: 24VDC; Icontacts max: 16 |
| Type of relay | electromagnetic |
| Contacts configuration | SPDT |
| Rated coil voltage | 24V DC |
| Contact current max | 16A |
| AC contacts rating @R | 16A / 250V AC |
| DC contacts rating @R | 16A / 30V DC |
| Switched voltage | max. 125V DC, |
| Relay variant | miniature |
| Mounting | PCB |
| Coil voltage min | 19.2V DC |
| Operate time | 15ms |
| Body dimensions | 29x13x25.5mm |
| Release time | 5ms |
| Mechanical durability | 20000000 cycles |
| Operating temperature | -40...70?C |
| Relay series | G2R |
| Contact resistance | 30m? |
| Terminal pitch | 5mm |
| Coil current | 21.8mA |
| Enclosure description | standard seal |
