Belt Drive Motor, Single Phase, Motor Design Permanent Split Capacitor, 1/3 HP, Nameplate RPM 1,625, No. of Speeds 1, Voltage 208-230V AC, Full Load Amps 2.3, 42Y Frame, OEM Replacement Brand Westinghouse, Usable @ 208V Yes, Usable @ 200V No, 60/50 Hz, Motor Service Factor 1, Motor Thermal Protection Auto, Ins. Class A, Max. Ambient Temp. 40 Degrees C, Motor Shaft Rotation CCWLE, Motor Enclosure Design Open Air-Over, Motor Mounting Type Cradle Base, Motor Mounting Position Horizontal

Belt Drive Motor, Single Phase, Motor Design Permanent Split Capacitor, 1/3 HP, Nameplate RPM 1,625, No. of Speeds 1, Voltage 208-230V AC, Full Load Amps 2.3, 42Y Frame, OEM Replacement Brand Westinghouse, Usable @ 208V Yes, Usable @ 200V No, 60/50 Hz, Motor Service Factor 1, Motor Thermal Protection Auto, Ins. Class A, Max. Ambient Temp. 40 Degrees C, Motor Shaft Rotation CCWLE, Motor Enclosure Design Open Air-Over, Motor Mounting Type Cradle Base, Motor Mounting Position Horizontal

Century . OWW4517

Gallery

Attributes

Brand name, Manufacturer name, ManufacturerCentury
CategoryId, CategoryIdL36493
CategoryIdL138
CategoryIdL29918
CategoryL1Power Transmission
CategoryL2Motors
CategoryL3HVAC Motors
CategoryL4OEM Replacement Motors
DimensionUnitinch
GraingerSku45GM13
UPCNone
UnitOfMeasureEA
Voltage208-230V
Weight13.25
WeightUnitlbs
cali_prop65_orglabel, cali_prop65_whtlabelFalse
countryOfOriginMX
height7.5
jsonUrlData924526ffbdad25e5923b
length22.6
moq, multiple, qtyInStock, qtyInStockOverride, tierMinQty1, No of Speeds, Number of Shafts, Phase1
MPNOWW4517
qtySourceqtyInStockOverride
SKUG2033501
tierPrice1219.99
urlhttps://www.zoro.com/century-motor-13-hp-oem-replacement-brand-westinghouse-oww4517/i/G2033501/
width7.2
Shaft Dia1/2"
Shaft Length7.2" x 7.2"
Length Less Shaft4 13/16 in
Body Dia4.88"
Manufacturers Warranty Length1 yr.
Overall Length18-1/2"
Frame42Y
HP1/3 HP
ItemMotor
Motor ApplicationOEM Replacement
Motor DesignPermanent Split Capacitor
Motor Enclosure DesignOpen Air-Over
Motor Mounting TypeResilient Base
Motor Shaft RotationCounterclockwise Lead End
Motor Sub ApplicationDirect Drive Fan/Blower
Motor Thermal ProtectionAutomatic
Nameplate RPM1625 rpm
OEM Replacement BrandWestinghouse
RPM Range1601-1700
Motor BearingsSleeve

Distributor offers

SellerSKUMOQIn stockMultiplePrices
ZoroG20335011111 @ $219.99
Global IndustrialB186463111 @ $164.95
Global IndustrialWBB1864631-211 @ $285.95
SupplyHouseOWW451711
AmazonSCB0091BC78M11
National Supply NetworkB1864631-211 @ $283.09
sustainablesupply.comC2090754111 @ $283.44
emotorpro.comOWW45171-211 @ $276.92
uri.comOWW45171-211 @ $610.94
midwestapplianceparts.comOWW4517-AO-P111 @ $280.51
Square OneOWW451711
bakerdist.comAOSOWW4517111 @ False
turtle.comAO2 OWW4517111 @ $483.93
homeessentialsdirect.comOWW45171-211 @ $290.71
hvacdiscountstore.comCEN--OWW4517111 @ $310.97
ptacsolutions.comOWW4517111 @ $327.62
ktool.netOWW45171-211 @ $224.38
Voomi SupplyOWW45171-211 @ $297.44
simsupply.comZO-G20335011311 @ $281.74
