YKEY 65W 12-24V Upgraded Original TS100 Digital OLED Programmable Pocket-size Portable Soldering Iron Station Kit with DC5525 Acceleration Sensors STM32 Chip (Black Color with 2 Tips): Maxedbuy.com
Gallery
Attributes
Distributor offers
| Seller | SKU | MOQ | In stock | Multiple | Prices |
|---|---|---|---|---|---|
| Maxedbuy | JC-TS100-G-2 | 1 | -2 | 1 | 1 @ $111.99 |
Related on Amazon
As an Amazon Associate, we earn from qualifying purchases. (paid link) CERTAIN CONTENT THAT APPEARS ON THIS SITE COMES FROM AMAZON. THIS CONTENT IS PROVIDED 'AS IS' AND IS SUBJECT TO CHANGE OR REMOVAL AT ANY TIME.
YKEY Original TS101 Smart USB-C Portable Digital Electronics Soldering Iron Station Kit Adjustable Temperature OLED Programmable Welding Tool TS100 Upgraded(TS-B2 Tip)
Brand: YKEY
TS101 Specifications: -Power input:DC-wide range, PD3.0. -Power: (DC)65W MAX; (PD3.0)45W MAX. -Temperature stability: ±2%. -Resistance of the solder tip to mass: <2Ω. -Temperature range: 50-400°C (max). -Max. operating temperature: 40°C. OLED screen. -USB-C port. -DC5525 connector. < Br> -Fashionable and removable. -Open source. Br> -To work efficiently. -Wide compatibility. < Br> -Control part: length: 98mm, diameter: 16.5mm. < Br> -Heating part: length: 105mm, diameter: 5.5mm. < Br> -Net weight of soldering iron: 33g . -Compliant with EU certification: CE FCC. < Package list: TS101 Soldering Iron Controller *1 TS-B2 soldering iron tip *1 USB-C Silicone Cable *1 Stand *1 User manual *1 Field Repairs It can be used for Field Repairing, but you need to get a PD 45W/65W/100W Power Bank or a battery, which is NOT included in the package. It can also be powered by other batteries with 9-24V output, but you need to find the right cable to connect it.
Details
- TS101 is an upgraded version of Mini Soldering Iron TS100. Based on TS100, TS101 has been upgraded and optimized in performance and function, to improve user experience.
- TS101 controller has a sharp and tough overall appearance, and uses a larger 128*32 pixel OLED screen to display more heating data. The classic A-B button operation continues the TS100 operation habit and reduces user’s learning cost.
- TS101 uses DC and PD dual power input. The power range of the popular DC5525 interface has been extended to DC 9-24V (up to 65W). A USB-C interface replaces the original Micro USB interface, which serves for firmware upgrade, and a standard PD power input up to 45W.
- The temperature adjustment range has also been optimized to 50-400℃ for more application scenarios.
- TS101 has more detailed menu setting items, and the newly added “Boost” heating function can quickly heat up in a short time to meet the welding needs of special scenes.
- TS101 and TS100 use the same soldering iron tips, so your existing TS100 soldering tips can continue to be used to this upgrade version iron.
Listing
| Binding | Misc. |
|---|---|
| Product group | Home Improvement |
| Product type | TOOLS |
| Part number | JC-TS100-G-2 |
| Label | YKEY |
| Manufacturer | YKEY |
YKEY New Blue Upgraded Original TS100 Digital Oled Programmable Pocket-size Field Repair Portable Soldering Iron Station Kit (With B2 Tip)
Brand: YKEY
Specifications: - Power: 65W. - Temperature stability: ±2%. - Soldering tip resistance to ground: < 2Ω. - Temperature range: 100 - 400°C (max). - Max operation ambient temperature: 40°C. - OLED screen. - Micro USB port. - DC5525 port. - Fashionable and detachable. - Open source. - Efficient to work with. - Wide compatibility. - Control part: length: 96mm, diameter: 16.5mm. - Heating part: length: 72+33mm, diameter: 5.5mm. - Net Weight of soldering iron: 33g . - Compliant with EU certification: CE FCC. Package List: TS100 Handle (Blue color) ×1 US Power Supply Adapter ×1 B2 Tip ×1 Earth clamps ×1 Soldering Stand ×1 User Manual ×1 Field Repairing It can be used for Outdoor Repairing, but you need to get a right connector and a portable battery with 12-24V output, which is NOT in cluded in this item We provide a XT60 Cable, which can be used with a 4S battery, or 6S battery, but battery is NOT included in package.
Details
- 【NEW Color Version】The new TS100 has Blue handle, with B2 Tip, power supply, XT60 cable, soldering stand, Earth clamps, and detailed user manual.
- 【Fast Heating】Working on 65W, DC 12-24V, this portable soldering iron heats up in seconds. The temperature is displayed on OLED screen, which can be accurately and easily adjusted from 212°F to 752°F (100°C to 400°C)
- 【Smart & Safe】It has dual-temperature sensors and accelerated sensors with STM32 chip. And it also has sleep mode and automatic over-heating warning.
- 【External power supply】We provide US power supply and XT60 cable. It's convenient for both home repairing and filed repairing.
- 【Reprogrammable】Connecting to the computer, you can reset your own temperature rising curves and custom functions.
Listing
| Binding | Misc. |
|---|---|
| Product group | Home Improvement |
| Product type | TOOLS |
| Part number | JC-TS100-G-2 |
| Label | YKEY |
| Manufacturer | YKEY |
Catalog
| Feature | \u3010Upgrade Version\u3011The new TS100 Soldering Tip has a shell cover, which is good for heat dissipation, and preventing your hand from touching the Iron. |
|---|---|
| Category | Tools & Home Improvement |
| MPN | JC-TS100-G-2 |
| UPC | 607376978683 |
| EAN | 607376978683 |
| Product group | Home Improvement |
| Product type | TOOLS |
| Manufacturer | YKEY |
