Tang Band W1-1925SB 1" Poly Cone Full Range Driver

Tang Band W1-1925SB 1" Poly Cone Full Range Driver. Part Number: 264-922 by Tang Band.

Tang Band . W1-1925SB

Gallery

Attributes

Brand name, Manufacturer name, Manufacturer, BrandTang Band
DimensionUnitinch
Extra Product NameTang Band W1-1925SB 1" Poly Cone Full Range Driver
UPC844632099403
Weight0.05
WeightUnitlbs
depth, length, Total Q (Qts)0.54
diameter, height, width1.0
height_Attrib, width_AttribNominal Diameter
length_AttribDepth
moq, multiple1
MPN, ModelW1-1925SB
qtyInStock0
SKU, Part Number264-922
snippetTang Band W1-1925SB 1" Poly Cone Full Range Driver. Part Number: 264-922 by Tang Band.
Unit of MeasureEach
Nominal Diameter, Overall Outside Diameter1"
Power Handling (RMS)3.5 Watts
Power Handling (MAX)7 Watts
Impedance4?
Frequency Response220 to 20,000Hz
Sensitivity75dB 2.83V/1m
Voice Coil Diameter0.5"
Resonant Frequency (Fs)220Hz
DC Resistance (Re)3.5?
Voice Coil Inductance (Le)0.008mH
Mechanical Q (Qms)0.61
Electromagnetic Q (Qes)0.82
Compliance Equivalent Volume (Vas)0.00052ft?
Mechanical Compliance of Suspension (Cms)2.4mm/N
BL Product (BL)1.12T?m
Maximum Linear Excursion (Xmax)0.75mm
Surface Area of Cone (Sd)2.3cm?
Cone MaterialPoly
Surround MaterialSantoprene?
Basket / Frame MaterialPolymer
Magnet MaterialNeodymium
Baffle Cutout Diameter0.93"
Depth0.54"
Sealed Volume, Vented Volume0.002ft?
Sealed F3332.2Hz
Vented F3164.6Hz
