HIGHLY Z15G1705 | Microswitch SNAP ACTION; with lever; SPDT; 20A/250VAC; ON-(ON)
HIGHLY Z15G1705 | Microswitch SNAP ACTION; with lever; SPDT; 20A/250VAC; ON-(ON
Gallery
Attributes
| Brand name, Manufacturer name, Manufacturer | HIGHLY |
|---|---|
| CategoryL1 | Switches and Indicators |
| CategoryL2 | Microswitches |
| CategoryL3 | Microswitches SNAP ACTION |
| DimensionUnit | mm |
| Extra Product Name | HIGHLY Z15G1705 | Microswitch SNAP ACTION; with lever; SPDT; 20A/250VAC; ON-(ON) |
| atoms, moq, multiple, tierMinQty1, Stable positions number | 1 |
| jsonUrlData | b5ef156b3a4c6a19eb2ec44d7fa82f69.5 |
| jsonUrlData2 | 6ca866b1d20c968fdcb8 |
| keywords | HIGHLY, Z15G1705, Switches and Indicators, Microswitches, Microswitches SNAP ACTION |
| length | 110.0 |
| length_Attrib | Lever length |
| MPN, SKU | Z15G1705 |
| qtyInStock | 3 |
| snippet | HIGHLY Z15G1705 | Microswitch SNAP ACTION; with lever; SPDT; 20A/250VAC; ON-(ON |
| tierMinQty2 | 5 |
| tierMinQty3 | 20 |
| tierMinQty4 | 100 |
| tierPrice1 | 5.28 |
| tierPrice2 | 4.64 |
| tierPrice3 | 4.2 |
| tierPrice4 | 3.78 |
| Type of switch | microswitch SNAP ACTION |
| Switches features | with lever |
| Contacts configuration | SPDT |
| AC contacts rating @R | 20A / 250V AC |
| AC contacts rating @L | 4A / 125V AC |
| Max contact resistance: | 15m? |
| Switching method | ON-(ON) |
| Number of positions | 2 |
| IP rating | IP40 |
| Leads | M4 screws |
| Body dimensions | 49.2x17.45x24.2mm |
| Mechanical durability | 1000000 cycles |
| Operating temperature | 0...55?C |
| Operating Force | 1.6N |
| Lever length | 110mm |
| Electrical life | 100000 cycles |
| Min insulation resistance | 100M? |
| Related items | AA8000 |
Distributor offers
| Seller | SKU | MOQ | In stock | Multiple | Prices |
|---|---|---|---|---|---|
| Z15G1705 | 1 | 3 | 1 | 1 @ $5.28, 5 @ $4.64, 20 @ $4.20, 100 @ $3.78 |
