Baldor VXL050522A 0.5HP 3450RPM 1PH 60HZ 56C 3420L XPFC F1 Motor - MROSupply.com

Shop Baldor VXL050522A and trust MRO to be your reliable Baldor supplier to experience the difference that quality and expertise can make. Trusted since 1898. Fast, Free Shipping.

Baldor . VXL050522A

Gallery

Attributes

Brand name, Manufacturer name, ManufacturerBaldor
CategoryL1Electric Motors
CategoryL2AC Motors
CategoryL3AC Explosion Proof/Hazardous Location Motors
DimensionUnitinch
Extra Product NameBaldor VXL050522A 0.5HP 3450RPM 1PH 60HZ 56C 3420L XPFC F1 Motor - MROSupply.com
diameter, height, width0.625
height_Attrib, width_AttribShaft Diameter
length14.22
length_AttribOverall Length
moq, multiple, Phase1
MPNVXL050522A
qtyInStock0
snippetShop Baldor VXL050522A and trust MRO to be your reliable Baldor supplier to experience the difference that quality and expertise can make. Trusted since 1898. Fast, Free Shipping.
Frame56C
EnclosureXPFC
Power factor60
Product familyGeneral Purpose
Shaft rotationReversible
Pull-up torque2.31 lb-ft
Lifting lugsNo lifting lugs
Synchronous speed @ frequency3600 RPM @ 60 HZ
Output @ frequency.500 HP @ 60 HZ
Motor lead terminationFlying leads
Agency approvalsCSA
XP class and groupCLI GP D; CLII GP F,G
Shaft ground indicatorNo shaft grounding
Inverter codeNot inverter
Locked bearing indicatorNo locked bearing
Insulation classB
Mounting arrangementF1
Starting current44.9 A
No-load current0 A
Break-down torque2.82 lb-ft
Frequency60.00 Hz
Pulley face codeC-face
Motor letter typeCap start, induction run
Overall Length14.22 in
Locked-rotor torque3.13 lb-ft
Current @ voltage4.700 A @ 230.0 V
Starting methodDirect on line
XP temp codeT3C
Shaft Diameter0.625 in
Heater indicatorNo heater
Motor standardsNEMA
Temp rise @ rated load69? C
Auxillary boxNo auxillary box
Electrically isolated bearingNot electrically isolated
Drip coverNo drip cover
Voltage @ frequency115.0 V @ 60 HZ
Duty ratingCONT
Frame materialSteel
Design code, KVA codeN
Bearing grease typePolyrex EM (-20F +300F)
Service factor1.00
Number of poles2
Feedback deviceNo feedback
Efficiency @ 100% load60.0 %
Winding thermal 1 locationEP
Winding thermal 1Automatic thermal overload
XP divisionDivision I
High voltage full load amps4.7 a
Full load torque0 lb-ft
Speed codeSingle speed
Line-line res @ 25? C0.782 Ohms A Ph / 2.48 Ohms B Ph
Vibration sensor indicatorNo vibration sensor
Motor type3420L
Speed3450 rpm
Base indicatorNo mounting
Ambient temperature (?C)40

Distributor offers

SellerSKUMOQIn stockMultiplePrices
MRO Supply617013111
GalcoVXL050522A-BLDR111 @ $759.68
emotorpro.comVXL050522A1-211 @ $686.56
