OD6015-05HB Orion Fans | Fans, Thermal Management | DigiKey
Fans Fan DC 60x15mm 5V 19CFM Ball (1 piece)
Gallery
Attributes
| Brand name, Manufacturer name, Manufacturer, Mfr | Orion Fans |
|---|---|
| Extra Product Name | OD6015-05HB Orion Fans | Fans, Thermal Management | DigiKey |
| atoms, minimum, moq, multiple | 1 |
| MPN | OD6015-05HB |
| qtyInStock | 495 |
| SKU | 1053-1228-ND |
| Part Status | Active |
| Voltage - Rated | 5VDC |
| Size / Dimension | Square - 60mm L x 60mm H |
| Width | 15.00mm |
| Air Flow | 16.0 CFM (0.448m?/min) |
| Static Pressure | 0.150 in H2O (37.3 Pa) |
| Bearing Type | Ball |
| Fan Type | Tubeaxial |
| Features | Auto Restart |
| Noise | 33.0dB |
| RPM | 4500 RPM |
| Termination | 2 Wire Leads |
| Ingress Protection, Voltage Range | - |
| Operating Temperature | 14 ~ 158?F (-10 ~ 70?C) |
| Approval Agency | cURus, TUV |
| Weight | 0.081 lb (36.74 g) |
| Current Rating (Amps) | 0.220A |
| Material - Frame, Material - Blade | Polybutylene Terephthalate (PBT) |
| Lifetime @ Temp | 60000 Hrs @ 40?C |
| Power (Watts) | 1.1 W |
Distributor offers
| Seller | SKU | MOQ | In stock | Multiple | Prices |
|---|---|---|---|---|---|
| Digi-Key | 1053-1228-ND | 1 | 495 | 1 | |
| OD6015-05HB | 1 | 20 | 1 | 1 @ $7.97, 25 @ $7.57, 100 @ $7.20, 500 @ $6.84, 1000 @ $6.27 | |
| Hotenda | H1900327 | 1 | 169 | 1 | 1 @ $9.15, 10 @ $8.71, 25 @ $8.17, 100 @ $7.24, 250 @ $6.81, 500 @ $6.67 |
 Carlton Bates Company | 40308486309 | 1 | 1 | 1 @ $0.00 | |
 AmazonTP | B00M295KLG | 1 | 1 | 1 @ $19.65 | |
 Newark | 89AH2577 | 1 | 18 | 1 | 1 @ $12.65, 5 @ $12.31, 10 @ $11.85, 25 @ $11.11, 50 @ $10.37, 100 @ $9.64 |
| Amazon | B00DWIGLOG | 1 | 1 | ||
| Digi-Key | 2621133 | 1 | 3073 | 1 | 1 @ $12.36, 10 @ $11.80, 25 @ $11.10, 50 @ $10.68, 100 @ $9.83, 250 @ $9.20, 500 @ $9.06 |
| OD6015-05HB-ORIN | 1 | 1 | 1 @ $13.12 | ||
| 10141921 | 1 | 1 | 1 @ $11.15 | ||
| us.rs-online.com | 70103579 | 1 | 520 | 1 | 1 @ $13.51, 5 @ $13.15, 10 @ $12.64, 25 @ $11.83, 50 @ $11.03, 100 @ $10.30 |
 Newark | 51AK1701 | 1 | 1 | 1 @ $17.99, 50 @ $16.49, 100 @ $15.25, 250 @ $14.29, 500 @ $13.47 |
