Mini circuit breaker, QO, 15A, 1 pole, 120/240VAC, 10kA, bolt on mount, fungal treatment | Mayer Electric

Mayer Electric Supply . QOB115FT

Gallery

Attributes

Brand name, Manufacturer name, ManufacturerMayer Electric Supply
DimensionUnitmm
Extra Product NameMini circuit breaker, QO, 15A, 1 pole, 120/240VAC, 10kA, bolt on mount, fungal treatment | Mayer Electric
UPC785901878490
Weight0.141
WeightUnitkg
Weight_AttribNet Weight
depth, length74.0
height76.0
height_AttribHeight
jsonUrlData/Product/SQUARE-D-MINIATURE-CIRCUIT-BREAKER-120-240V-15A-785901878490
jsonUrlData268397b3f-0695-4b1c-89d4-abd20062de8e
length_AttribDepth
moq, multiple, tierMinQty1, Number Of Spaces Required1
MPNQOB115FT
qtyInStock0
SKUSQDQOB115FT
tierPrice138.58
width19.0
width_AttribWidth
Circuit Breaker ApplicationHACR and Switching Duty rated
Circuit Breaker Typestandard
Mounting Modebolt-on
Range Of ProductQO
Poles Description1P
Electrical Connectionpressure plate
Line Rated Current15 A
Product Or Component Typeminiature circuit-breaker
[Ue] Rated Operational Voltage120/240 V AC || 120 V AC || 48 V DC
Warranty18 months
Height76 mm
Breaking Capacity10 kA 120/240 V AC 50/60 Hz || 10 kA 120 V AC 50/60 Hz || 5 kA 48 V DC
Tightening Torque4.6-4.6 N.m
Awg GaugeAWG 14...AWG 8 copper or aluminium
Width19 mm
Depth74 mm
Net Weight0.141 kg
China Rohs RegulationProduct out of China RoHS scope. Substance declaration for your information.
Rohs Exemption Information, Mercury Free, Toxic Heavy Metal FreeYes
Sustainable Offer StatusGreen Premium product
Eu Rohs DirectiveCompliant
Reach RegulationReference contains Substances of Very High Concern above the threshold
California Proposition 65 : WARNING: This product can expose you to chemicals includingLead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
Product CertificationsUL Listed || CSA
Ambient Air Temperature For Operation40 ?C

Distributor offers

SellerSKUMOQIn stockMultiplePrices
mayerelectric.comSQDQOB115FT111 @ $38.58
