Order YA31L2NTC516 by Burndy Cu Compression Terminal, 2 Nema Holes, (Pack of 10 pcs) - US Mega Store

Burndy, YA31L2NTC516, Cu Compression Terminal, 2 Nema Holes w/ Inspection Window, 350 Kcmil Code,350 Navy, 5/16" Stud, Standard Barrel.

Burndy . YA31L2NTC516

Gallery

Attributes

Brand name, Manufacturer name, ManufacturerBurndy
CategoryL1Networking & Wiring
CategoryL2Wire Connectors
CategoryL3Burndy YA31L2NTC516
ConditionNEW
DimensionUnitinch
Extra Product NameOrder YA31L2NTC516 by Burndy Cu Compression Terminal, 2 Nema Holes, (Pack of 10 pcs) - US Mega Store
diameter, height, length0.88
height_Attrib, length_AttribDimension - Outside Diameter inch
moq, multiple, tierMinQty11
MPN, SKUYA31L2NTC516
qtyInStock-2
qtySourceFieldMap
snippetBurndy, YA31L2NTC516, Cu Compression Terminal, 2 Nema Holes w/ Inspection Window, 350 Kcmil Code,350 Navy, 5/16" Stud, Standard Barrel.
tierPrice135.11
width1.29
width_AttribDimension - Pad Width inch
Color CodeRed
Connector TypeTerminal
Die Index18;324
Feature - Barrel StyleChamfered
Feature - Barrel TypeStandard
Material, Conductor - MaterialCopper
Physical Attribute - Number of Holes2
PlatedY
Plating TypeTin
Trade NameHYLUG
TypeStandard Barrel, Tin Plated
Dimension - B Length fraction1-1/16 in
Dimension - B Length inch1.06 in
Dimension - Bolt Hole Size inch, Dimension - Hole Size inch0.33 in
Dimension - Bolt Size fraction, Dimension - Stud Size inch5/16
Dimension - Hole Size mm8 mm
Dimension - L Length Overall mm105 mm
Dimension - Length Overall inch4.13 in
Dimension - N inch0.34 in
Dimension - Outside Diameter inch0.88 in
Dimension - Pad Width inch1.29 in
Dimension - Strip Length inch1-1/8
Dimension - Z inch0.36 in
Physical Attribute - Tongue AngleStraight
Rating - KVA35 kV
Rating - Minimum Voltage600
Voltage - Maximum35000
Conductor - Copper Str Navy Size350 (91) Navy
Conductor - Copper Str Size, Conductor - Copper Str Size Range350 kcmil

Distributor offers

SellerSKUMOQIn stockMultiplePrices
usmegastore.comYA31L2NTC5161-211 @ $35.11
Graybar25473889111 @ $37.84
