BFU530WX NXP USA Inc. | Discrete Semiconductor Products | DigiKey
RF Transistor NPN 12V 40mA 11GHz 450mW Surface Mount SC-70
Attributes
| Brand name, Manufacturer name, Manufacturer, Mfr | NXP USA Inc. |
|---|---|
| Extra Product Name | BFU530WX NXP USA Inc. | Discrete Semiconductor Products | DigiKey |
| atoms, moq, multiple, tierMinQty1 | 1 |
| extraShipping, qtyInStock | 0 |
| MPN | BFU530WX |
| packaging | Cut Tape (CT) & Digi-Reel? |
| SKU | 4843129 |
| snippet | RF Transistor NPN 12V 40mA 11GHz 450mW Surface Mount SC-70 |
| tierMinQty2 | 10 |
| tierMinQty3 | 25 |
| tierMinQty4 | 100 |
| tierMinQty5 | 250 |
| tierMinQty6 | 500 |
| tierMinQty7 | 1,000 |
| tierMinQty8 | 3,000 |
| tierPrice1 | 0.58000 |
| tierPrice2 | 0.50800 |
| tierPrice3 | 0.47760 |
| tierPrice4 | 0.38960 |
| tierPrice5 | 0.36192 |
| tierPrice6 | 0.30800 |
| tierPrice7, tierPrice8 | 0.25564 |
| Category | Discrete Semiconductor Products |
| Series | Automotive, AEC-Q101 |
| Package | Tape & Reel (TR) |
| Product Status | Active |
| Transistor Type | NPN |
| Voltage - Collector Emitter Breakdown (Max) | 12V |
| Frequency - Transition | 11GHz |
| Noise Figure (dB Typ @ f) | 0.6dB @ 900MHz |
| Gain | 18.5dB |
| Power - Max | 450mW |
| DC Current Gain (hFE) (Min) @ Ic, Vce | 60 @ 10mA, 8V |
| Current - Collector (Ic) (Max) | 40mA |
| Operating Temperature | -40?C ~ 150?C (TJ) |
| Mounting Type | Surface Mount |
| Package / Case | SC-70, SOT-323 |
| Supplier Device Package | SC-70 |
| Base Product Number | BFU530 |
Distributor offers
| Seller | SKU | MOQ | In stock | Multiple | Prices |
|---|---|---|---|---|---|
| Digi-Key | 4843129 | 1 | 1 | 1 @ $0.58, 10 @ $0.51, 25 @ $0.48, 100 @ $0.39, 250 @ $0.36, 500 @ $0.31, 1000 @ $0.26, 3000 @ $0.26 | |
| Hotenda | H1918236 | 1 | 1 | 1 @ $0.14 | |
 iodParts | BFU530WX | 1 | 1 | ||
| Digi-Key | 4895785 | 1 | 1 | 1 @ $0.44, 10 @ $0.37, 25 @ $0.35, 100 @ $0.28 | |
| Newark | 95AC8174 | 3000 | 3000 | 3000 @ $0.26, 6000 @ $0.24, 12000 @ $0.22, 18000 @ $0.21, 30000 @ $0.20 | |
| Newark | 41X4109 | 3000 | 3000 | 3000 @ $0.26, 6000 @ $0.24, 12000 @ $0.22, 18000 @ $0.21, 30000 @ $0.20 | |
 Newark | 31AC6240 | 1 | 2350 | 1 | 1 @ $0.41, 10 @ $0.35, 25 @ $0.33, 50 @ $0.31, 100 @ $0.29, 250 @ $0.28 |
| Digi-Key | 4895805 | 1 | 19925 | 1 | 1 @ $0.58, 10 @ $0.51, 25 @ $0.48, 100 @ $0.39, 250 @ $0.36, 500 @ $0.31, 3000 @ $0.31 |
 Arrow | BFU530WX | 1 | 8 | 1 | 1 @ $0.29, 10 @ $0.29, 100 @ $0.29, 1000 @ $0.29, 10000 @ $0.29 |
| Mouser | 771-BFU530WX | 1 | 6146 | 1 | 1 @ $0.53, 10 @ $0.43, 100 @ $0.29, 1000 @ $0.17, 10000 @ $0.17 |
| Digi-Key | 15636278 | 2033 | 3402 | 2033 | 2033 @ $0.15 |
| BFU530WX | 1 | 2965 | 1 | 1 @ $1.04, 5 @ $0.53, 25 @ $0.47, 100 @ $0.42, 500 @ $0.38 |
