Diamond Turning Insert, Diamond, 3/8", 35 Degrees, 1/64"
Gallery
Attributes
| Brand name, Manufacturer name, Manufacturer, Label, Publisher, Studio | Kyocera |
|---|---|
| CategoryL1 | Tools & Machining |
| CategoryL2 | Cutting Tools |
| CategoryL3 | Indexable Tools |
| DimensionUnit | inch |
| GraingerSku | 185JZ5 |
| Extra Product Name | Diamond Turning Insert, Diamond, 3/8", 35 Degrees, 1/64" |
| UPC | None |
| UnitOfMeasure | EA |
| Weight | 0.25 0.01 |
| WeightUnit | lbs |
| cali_prop65_cancercausechem | Cobalt metal powder |
| cali_prop65_message | WARNING: This product can expose you to chemicals including Cobalt metal powder, which is known to the State of California to cause cancer. For more information go to www.P65Warnings.ca.gov. |
| cali_prop65_orglabel, AdultProduct, Autographed, Memorabilia, TradeInEligible | False |
| cali_prop65_warnmsgscenario, tierMinQty1, Corner Radius, Item_package_quantity, NumberOfItems, Number_of_items, PackageQuantity | 1 |
| cali_prop65_whtlabel | True |
| countryOfOrigin | JP |
| extendedLead | 2 |
| height | 0.39 |
| jsonUrlData | 924526ffbdad25e5923b |
| length | 4.13 |
| moq, multiple | 10 |
| MPN, Keyword, PartNumber, Part_number | VNMG331VFCA025P |
| qtyInStock, qtyInStockOverride | 0 |
| qtySource | qtyInStockOverride |
| SKU | G7433178 |
| tierPrice1 | 10.63 |
| url | https://www.zoro.com/kyocera-diamond-turning-insert-diamond-38-35-degrees-164-vnmg331vfca025p/i/G7433178/ |
| width | 1.77 |
| Through Hole Inside Dia | 0.1500" |
| Item | Diamond Turning Insert |
| Insert Shape, General Shape | Diamond |
| Inscribed Circle, Thickness | 3 |
| Included Angle | 35 Degrees |
| Chip-Breaker | Yes |
| ISO Number | VNMG160404VF |
| Cutting Direction | Neutral |
| Rake | Negative |
| Features | Thickened Alumina with Good Thermal Resistance (Twice as Thick as Conventional Coating) and Specialized Post-Coating Process Prevents Adhesion |
| Primary Material Application ISO Code | P |
| ANSI Code | VNMG331VF |
| Material Grade - Machining | Micro Columnar Coating Structure |
| Clearance Angle | 0 Degrees |
| Cutting Application | Copying, External Turning, Facing, General to Interrupted Cutting, Undercutting |
| Chip-Breaker Code | VF |
| Number of Cutting Edges | 4 |
| Finish - Machining | TiCN+Al2O3+TiN |
| Manufacturer Grade | CA025P |
| Primary Material Application | Steel |
| Coating Process | CVD |
| ASIN, Asin | B08W282WT3 |
| Brand | KYOCERA Kyocera |
| Bullet_point | 4 Cutting Edges Application: General to interrupted machining of steel Insert for External Turning, Copying, Facing, Undercutting Thickened alumina with good thermal resistance (twice as thick as conventional coating) and specialized post-coating process prevents adhesion. |
| ClassificationId | 257522011 |
| DisplayName | Turning Inserts |
| Height, Width | 1000 500 75 |
| Identifier | 4960664865581 |
| IdentifierType | EAN |
| ItemClassification | BASE_PRODUCT |
| ItemName, Item_name, Title | Kyocera VNMG 331VF CA025P Grade CVD Carbide, 0 Degree, Diamond, Negative Rake Angle, Neutral Turning Insert for Light Interruption and Finishing-Medium in (P) Carbon/Alloy Steel (10 Pieces) |
| Item_type_keyword | turning-inserts |
| Link | https://m.media-amazon.com/images/I/41llXRRE2tL._SL75_.jpg https://m.media-amazon.com/images/I/41llXRRE2tL.jpg https://m.media-amazon.com/images/I/5162Qpw-H6L.jpg |
| Material, MaterialType | Carbide |
| ProductGroup, WebsiteDisplayGroupName | BISS Basic |
| ProductType, ProductTypeName | CUTTING_TOOLS |
| Product_description | Insert for External Turning, Copying, Facing, Undercutting 4 Cutting Edges Thickened alumina with good thermal resistance (twice as thick as conventional coating) and specialized post-coating process prevents adhesion. Application: General to interrupted machining of steel Product Details: Insert Style: VNMG Insert Size: 331 Chipbreaker: VF Insert Grade: CA025P Material: Carbide Material Grade: Micro Columnar Coating Process: CVD Coating / Composition: TiCn/al2O3/TiN [IC] Inscribed Circle (Decimal Inch): 0.3750 [IC] Inscribed Circle (mm): 9.53 [S] Thickness (Decimal Inch): 0.1875 [S] Thickness (mm): 4.76 [RE] Corner Radius (Decimal Inch): 0.0156 [RE] Corner Radius (mm): 0.40 [D1] Hole Diameter (Decimal Inch): 0.1500 [D1] Hole Diameter (mm): 3.81 Rake: Negative [AN] Relief Angle (Degree): 0 Included Angle (Degree): 35 Primary Workpiece Material: Steel Shape: Diamond Insert Hand: Neutral Insert Holding Method: Screw Number of Cutting Edges: 4 Application: External Turning, Copying, Facing, Undercutting Usage Classification: Light Interruption Hole (Yes/No): Yes Cutting Range: Finishing Compatible Holders (Partial): DVJNR...-3…, DVJNL...-3…, DVLNR...-16, DVLNL...-16, DVPNR...-3…, DVPNL...-3…, DVPNR...-16, DVPNL...-16, DVVNN...-16, MVJNR...-3…, MVJNL...-3…, MVLNR...-16, MVLNL...-16, MVVNN...-3..., PVLNR...-16..., PVLNL...-16..., PVPNR...-16…, PVPNL...-16…, PVVNN...-16… CA025P Product Brochure |
| Product_site_launch_date | 2019-02-14T20:07:16.449Z |
| Style | ISOI |
| Type | ean |
| URL | https://m.media-amazon.com/images/I/41llXRRE2tL._SL75_.jpg |
| Units | pixels pounds |
| Variant | MAIN |
| WebsiteDisplayGroup | biss_basic_display_on_website |
Distributor offers
| Seller | SKU | MOQ | In stock | Multiple | Prices |
|---|---|---|---|---|---|
| G7433178 | 10 | 10 | 1 @ $10.63 |
Related on Amazon
As an Amazon Associate, we earn from qualifying purchases. (paid link) CERTAIN CONTENT THAT APPEARS ON THIS SITE COMES FROM AMAZON. THIS CONTENT IS PROVIDED 'AS IS' AND IS SUBJECT TO CHANGE OR REMOVAL AT ANY TIME.
Kyocera VNMG 331VF CA025P Grade CVD Carbide, 0 Degree, Diamond, Negative Rake Angle, Neutral Turning Insert for Light Interruption and Finishing-Medium in (P) Carbon/Alloy Steel (10 Pieces)
Brand: KYOCERA
Insert for External Turning, Copying, Facing, Undercutting 4 Cutting Edges Thickened alumina with good thermal resistance (twice as thick as conventional coating) and specialized post-coating process prevents adhesion. Application: General to interrupted machining of steel Product Details: Insert Style: VNMG Insert Size: 331 Chipbreaker: VF Insert Grade: CA025P Material: Carbide Material Grade: Micro Columnar Coating Process: CVD Coating / Composition: TiCn/al2O3/TiN [IC] Inscribed Circle (Decimal Inch): 0.3750 [IC] Inscribed Circle (mm): 9.53 [S] Thickness (Decimal Inch): 0.1875 [S] Thickness (mm): 4.76 [RE] Corner Radius (Decimal Inch): 0.0156 [RE] Corner Radius (mm): 0.40 [D1] Hole Diameter (Decimal Inch): 0.1500 [D1] Hole Diameter (mm): 3.81 Rake: Negative [AN] Relief Angle (Degree): 0 Included Angle (Degree): 35 Primary Workpiece Material: Steel Shape: Diamond Insert Hand: Neutral Insert Holding Method: Screw Number of Cutting Edges: 4 Application: External Turning, Copying, Facing, Undercutting Usage Classification: Light Interruption Hole (Yes/No): Yes Cutting Range: Finishing Compatible Holders (Partial): DVJNR...-3…, DVJNL...-3…, DVLNR...-16, DVLNL...-16, DVPNR...-3…, DVPNL...-3…, DVPNR...-16, DVPNL...-16, DVVNN...-16, MVJNR...-3…, MVJNL...-3…, MVLNR...-16, MVLNL...-16, MVVNN...-3..., PVLNR...-16..., PVLNL...-16..., PVPNR...-16…, PVPNL...-16…, PVVNN...-16… CA025P Product Brochure
Details
- Insert for External Turning, Copying, Facing, Undercutting
- 4 Cutting Edges
- Thickened alumina with good thermal resistance (twice as thick as conventional coating) and specialized post-coating process prevents adhesion.
- Application: General to interrupted machining of steel
Listing
| Product group | BISS Basic |
|---|---|
| Product type | CUTTING_TOOLS |
| Part number | VNMG331VFCA025P |
| Items per pack | 1 |
| Label | Kyocera |
| Manufacturer | Kyocera |
