Widia

Widia . 4IRN55

Gallery

Attributes

Brand name, Manufacturer name, Manufacturer, Extra Product NameWidia
DimensionUnitinch
GraingerSku273MT7
UPC4021169206641
UnitOfMeasureEA
Weight0.2
WeightUnitlbs
cali_prop65_messageWARNING: Cancer - www.P65Warnings.ca.gov
cali_prop65_orglabelFalse
cali_prop65_warnmsgscenario, Min Thread per Inch5
cali_prop65_whtlabelTrue
countryOfOriginIL
extendedLead42
extendedQty-2
height2.44
jsonUrlData924526ffbdad25e5923b
length0.41
moq, multiple10
MPN, ISO Number, ANSI Code4IRN55
qtyInStock0
qtyInStockOverrideDrop Ship
SKUG3875783
tierMinQty11
tierPrice129.36
urlhttps://www.zoro.com/widia-threading-insert-4irn-triangle-4irn55/i/G3875783/
width3.09
ItemThreading Insert
Thread Type55 Degree Partial
StylePartial Profile
Insert Size4
Chip-BreakerNo
Grade, Manufacturer GradeTN6025
Cutting Direction, Thread DirectionRight Hand
Inscribed Circle, Insert Holding Type1/2 in
Insert ShapeTriangle
Material - MachiningCarbide
Finish - MachiningAlTiN
Thread StandardPartial Profile 55 Degrees
Measurement SystemMetric
Thread Height Difference1.70mm
Side-to-Cutting Tip2.50mm
Clearance Angle0 Degrees
Thread Profile TypePartial
Thickness4.64mm
Max Thread Pitch7
Cutting ApplicationTurning
Feed TypeHigh
Insert Style4IRN
Threading LocationInternal
Secondary Material ApplicationAluminum, Brass, Bronze, Copper
Coating ProcessPVD
Insert Length22.00mm
Secondary Material Application ISO CodeN
Thread Pitch3.50mm to 5.00mm
Number of Cutting Edges3
Included Angle55 Degrees
Min Thread Pitch3.50mm
Primary Material Application ISO CodeK, M, P, S
Corner Radius0.43mm
Primary Material ApplicationCast Iron, Nickel, Stainless Steel, Steel, Titanium
Country of Origin (subject to change)Israel

Distributor offers

SellerSKUMOQIn stockMultiplePrices
ZoroG387578310101 @ $29.36
