Ciare PWA12.75 12" Woofer 8 Ohm

Ciare . PWA12.75

Gallery

Attributes

Brand name, Manufacturer name, Manufacturer, BrandCiare
DimensionUnitinch
Extra Product NameCiare PWA12.75 12" Woofer 8 Ohm
UPC848864075563
Weight16.25
WeightUnitlbs
depth, length5.35
diameter, height, width12.32
height_Attrib, width_AttribOverall Outside Diameter
length_AttribDepth
moq, multiple1
MPN, ModelPWA12.75
qtyInStock-2
qtySourceFieldMap
SKU, Part Number293-188
Unit of MeasureEach
Nominal Diameter12"
Bolt Circle Diameter11.77
Power Handling (RMS)450 Watts
Power Handling (MAX)900 Watts
Impedance8?
Frequency Response50 to 3,000Hz
Sensitivity97.5dB 2.83V/1m
Voice Coil Diameter3"
Resonant Frequency (Fs)53Hz
DC Resistance (Re)5.4?
Voice Coil Inductance (Le)1.06mH
Mechanical Q (Qms)4.1
Electromagnetic Q (Qes)0.32
Total Q (Qts)0.3
Compliance Equivalent Volume (Vas)1.84ft?
BL Product (BL)19.6T?m
Diaphragm Mass Inc Airload (Mms)70g
Maximum Linear Excursion (Xmax)5.8mm
Surface Area of Cone (Sd)531cm?
Cone MaterialPaper-Treated Paper
Surround MaterialCloth
Voice Coil Wire MaterialCopper
Voice Coil FormerFiberglass
Basket / Frame MaterialSteel
Magnet MaterialFerrite
Overall Outside Diameter12.32"
Baffle Cutout Diameter11.1"
Depth5.35"
# Mounting Holes8
Sealed Volume0.234ft?
Sealed F3151.9Hz
Vented Volume0.541ft?
Vented F392.33Hz
