Adire Audio ADKO12D2 Koda 12" Subwoofer

Adire Audio ADKO12D2 Koda 12" Subwoofer - Part Number: 294-148 by Adire Audio.

Adire Audio . ADKO12D2

Gallery

Attributes

Brand name, Manufacturer name, Manufacturer, BrandAdire Audio
DimensionUnitinch
Extra Product NameAdire Audio ADKO12D2 Koda 12" Subwoofer
UPC753459913161
Weight22
WeightUnitlbs
depth, length5.625
diameter, height, width12.5
height_Attrib, width_AttribOverall Outside Diameter
length_AttribDepth
moq, multiple1
MPN, ModelADKO12D2
qtyInStockBack-Ordered
SKU, Part Number294-148
snippetAdire Audio ADKO12D2 Koda 12" Subwoofer - Part Number: 294-148 by Adire Audio.
Unit of MeasureEach
Nominal Diameter12"
Power Handling (RMS)250 Watts
Power Handling (MAX)500 Watts
Impedance8?
Sensitivity87.29dB 2.83V/1m
Resonant Frequency (Fs)27.39Hz
DC Resistance (Re)3.46?
Mechanical Q (Qms)4.61
Electromagnetic Q (Qes)0.48
Total Q (Qts)0.43
Compliance Equivalent Volume (Vas)84.5ft?
Mechanical Compliance of Suspension (Cms)0.23mm/N
BL Product (BL)13.35T?m
Diaphragm Mass Inc Airload (Mms)145.67g
Maximum Linear Excursion (Xmax)15mm
Surface Area of Cone (Sd)506.7cm?
Cone MaterialPaper / Glass Fiber
Voice Coil Wire MaterialCopper
Magnet MaterialFerrite
Overall Outside Diameter12.5"
Baffle Cutout Diameter11.125"
Depth5.625"
# Mounting Holes8
Sealed Volume1.3ft?
Sealed F349.7Hz
Vented Volume2.625ft?
Vented F328Hz
