OD1232-48MB02A Orion Fans | Fans, Thermal Management | DigiKey
Fan Tubeaxial 48VDC Square - 120mm L x 120mm H Ball 107.0 CFM (3.00m?/min) 3 Wire Leads
Gallery
Attributes
| Brand name, Manufacturer name, Manufacturer, Mfr | Orion Fans |
|---|---|
| Extra Product Name | OD1232-48MB02A Orion Fans | Fans, Thermal Management | DigiKey |
| atoms, minimum, moq, multiple | 1 |
| MPN | OD1232-48MB02A |
| qtyInStock | 50 |
| SKU | 1053-1638-ND |
| Part Status | Active |
| Voltage - Rated | 48VDC |
| Size / Dimension | Square - 120mm L x 120mm H |
| Width | 32.00mm |
| Air Flow | 107.0 CFM (3.00m?/min) |
| Static Pressure | 0.330 in H2O (82.2 Pa) |
| Bearing Type | Ball |
| Fan Type | Tubeaxial |
| Features | Locked Rotor Sensor |
| Noise | 48.0dB |
| RPM | 3300 RPM |
| Termination | 3 Wire Leads |
| Ingress Protection, Weight | - |
| Operating Temperature | -4 ~ 176?F (-20 ~ 80?C) |
| Approval Agency | CE, cURus |
| Current Rating (Amps) | 0.150A |
| Voltage Range | 24 ~ 55.2VDC |
| Material - Frame, Material - Blade | Polybutylene Terephthalate (PBT), Fiberglass Reinforced |
| Lifetime @ Temp | 60000 Hrs @ 40?C |
Distributor offers
| Seller | SKU | MOQ | In stock | Multiple | Prices |
|---|---|---|---|---|---|
| 1053-1638-ND | 1 | 50 | 1 | ||
| Hotenda | H1906949 | 1 | 40 | 1 | 1 @ $25.05, 10 @ $22.77, 25 @ $22.01, 100 @ $18.98, 250 @ $18.60, 500 @ $18.52 |
 Carlton Bates Company | 40308486095 | 1 | 1 | 1 @ $0.00 | |
| 2705915 | 1 | 10 | 1 | 1 @ $29.35, 10 @ $26.81, 25 @ $25.79, 50 @ $24.09, 100 @ $22.23, 250 @ $21.89 | |
| 10142143 | 1 | 1 | 1 @ $28.00 | ||
| us.rs-online.com | 70807622 | 1 | 1 | 1 @ $26.46, 3 @ $25.39 |
