MITSUBISHI . Q64AD2DA

[Certification]UL,cUL,CE [Number of Analog Input Points]4 points(4 channels) [Analog Inpu] -10 to 10VDC(input resistance value 1M Ohm) 0 to 20mADC(input resistance value 250 Ohm) [Digital output] Normal resolution mode:-96 to 4095,-4096 to 4095 -1096 to 4595 High resolution mode:-384 to 16383,-288 to 12287 -16384 to 16383,-3288 to 13787 [Conversion Time]500 microsiemens/channel [Absolute Maximum Input]Voltage:+/- 15V,current:+/- 30mA [Number Of Analog Output Points]2 points(2 channels) [Digital Input]Normal resolution mode:-96 to 4095,-4096 to 4095; High resolution mode:-288 to 12287,-16384 to 16383 [Analog Output] Voltage Voltage -10 to 10VDC(External load resistance:1M Ohm) Current 0 to 20mADC(External load resistance:600 Ohm) [Conversion Speed]500 microsiemens/channel [Absolute Maximum Output]Voltage:12V Current:21mA [Output Short Circuit Protection]Available [I/O Device Points Occupied]16 points(I/O assignment:Intelligent 16 points) [16 points(I/O assignment:Intelligent 16 points)]18 points terminal blockApplicable Solderless Terminal]A/D conversion part,D/A conversion part:R1.25-3(Solderless terminalswith sleeves are unavailable.) External power supply 24VDC,FG terminal connection:Not available [External Supply Power]24VDC 15%; Ripple,spike 500mVP-P or less; Inrush current:2.5A 150microamperes or less; Current consumption:0.19A [Internal Current Consumption(5VDC)]0.17A [Weight(kg)]0.23 [Base Unit Slots Occupied]1 (1)
