| Brand name, Manufacturer name, Manufacturer | Lorex |
|---|
| moq, multiple, tierMinQty1 | 1 |
|---|
| MPN, SKU | LW1080-44W |
|---|
| qtyInStock | -2 |
|---|
| tierPrice1 | 660.00 |
|---|
| Operating System | Linux (embedded) |
|---|
| Pentaplex | Simultaneous View, Record, Playback, Backup & Remote Monitoring |
|---|
| Number of Channels | 8 channels |
|---|
| Video IN | 8 x 1Vp-p, CVBS, 75ohms, BNC |
|---|
| Video OUT | No |
|---|
| VGA OUT, HDMI, Covert Video, Audio Play, Microphone | Yes |
|---|
| Audio IN | 1 lines IN (RCA) |
|---|
| Audio OUT | 1 line OUT (RCA) |
|---|
| USB Port | 1 at the back, 1 at the front |
|---|
| Alarm IN, Alarm OUT, DDNS | None |
|---|
| Video Output Resolution | HDMI: 3840x2160; 2560x1440; 1920x1200; 1600x1200; 1680x1050; 1920x1080; 1440x900;1280x1024; 1280x720; 1024x768 |
|---|
| PTZ Control | RS-485 Pelco D & P Protocol |
|---|
| Live Display | 1, 4, 8 |
|---|
| Live Display Speed | 240 NTSC, 200 PA |
|---|
| OSD | ON/OFF |
|---|
| System Navigation | USB Mouse, IR Remote Controller, Front Pane |
|---|
| Motion Area Setting | Fixed Grid 396 pixels (22x18) NTSC/PAL |
|---|
| Sensitivity | 100 |
|---|
| Firmware Upgrade | Automatic over the Internet & via USB device and Network |
|---|
| User Authority | By user group |
|---|
| Time Synchronization | Auto time sync by NTP server |
|---|
| Video Compression | H.264+ |
|---|
| Audio Compression | G.711 |
|---|
| Recording Resolution Setting | 1080p (1920x1072) |
|---|
| Recording Quality Control | 3 levels (High / Medium / Low) |
|---|
| Recording Schedule | 4K/8MP (3840x2160), 2K/4MP (2688x1520), 3MP(2304x1296), 1080p (1920x1080), 720p (1280x720),960x480, 704x480, 352x480, 704x240, 352x240, 176x120 |
|---|
| Recording Frame Rate | 4K@7fps (per ch), 4MP@15fps (per ch), 3MP/1080p/720p/960H: 30fps (NTSC) |
|---|
| Pre Recording | Max. 30 Secs |
|---|
| Post Recording | Max. 5 Minutes |
|---|
| Reliability | Watch-Dog, Auto-recovery alter power failure |
|---|
| Playback Channel | 1 / 4 / 8 |
|---|
| Playback Speed | Variable Max 4x |
|---|
| Playback Players | Backup Player |
|---|
| Search | By Time/Date & Motion Event |
|---|
| Log Search | Up to 1000 lines for system, configuration changes, motion/alarm detected, account, record & storage |
|---|
| Storage | Up to 1 HDD (SATA) |
|---|
| Maximum Capacity | Up to 1 x 8TB |
|---|
| Backup Media | USB Flash Drive & HDD |
|---|
| Backup File Format | DAV/ASF file |
|---|
| Cloud Connection | Lorex Cloud Connectivity |
|---|
| Supported Operating Systems | Windows Mac OSX |
|---|
| Remote Software | Client Software (PC) & Safari (Mac) |
|---|
| Email Notification | Text with snapshot |
|---|
| Instant Smart Phone | iPad, iPhone, Android |
|---|
| System Configuration | Full setup configuration over network |
|---|
| Ports | Programmable by User |
|---|
| Network Protocol | HTTP, IPv4/IPv6, TCP/IP, UPNP, RTSP, UDP, SMTP, NTP,DHCP, DNS, PPPOE, DDNS, FTP, IP |
|---|
| Network Interface | 10/100-Base-TX, RJ-45 |
|---|
| Network Speed Control | Max 64Mbps |
|---|
| Power Consumption | Approx. 10W (no HDD included) |
|---|
| Supply Voltage | 100VAC-240VAC, 12VDC, 2A, 50/60Hz |
|---|
| Unit Dimensions | 12.8 x 10.0 x 2.2" / 325 x 255 x 55mm |
|---|
| Unit Weight | 3.3lb / 1.5kg (without hard drive |
|---|
| Operating Temperature | 14°F ~ 130°F / -10°C ~ 55°C |
|---|
| Humidity | 10 ~ 90% RH |
|---|
| Transmission Frequency | 2.4 GHz (2412MHz~2462MHz) |
|---|
| Transmission Power | 17dBm |
|---|
| Unobstructed Wireless Range | 600ft (183m) outdoor / 165ft (50m) indoor |
|---|
| Transmission Type | DSSS |
|---|
| Modulation | OFDM and CCK |
|---|
| Operating Humidity | < 90% |
|---|
| Image Sensor | 1/2.7" Color CMOS |
|---|
| Supported Resolution | 1080p |
|---|
| Effective Pixels | H: 1932 V: 1092 |
|---|
| Minimum Illumination | 0 Lux with IR Illumination |
|---|
| AGC | On |
|---|
| AES Speed | 1/60 ~ 1/62,500 Sec. |
|---|
| IR LEDs | 18 pieces |
|---|
| Lens / Lens Type | 2.8mm F2.0 |
|---|
| Night Vision Range | 115ft (35m) / 75ft (23m) |
|---|
| Environmental Rating | IP66 (Indoor / Outdoor) |
|---|
| Field of View | 118° (D) 85° (H) |
|---|
| Power Supply | 12Vdc +/- 10% |
|---|
| Dimensions (W x D x H) | 3.2 x 6.1 x 5.6" / 82 x 155 x 143mm (with sunshade and antenna) |
|---|
| Weight | 0.34 kg / 0.7 lbs |
|---|
| Receiving Sensitivity | -88 dBm |
|---|
| Supported Resolutions | 1080p up to 10fps |
|---|
| Termination | BNC Video/CVI format |
|---|
| Image Compression | H.264 |
|---|
