Mini circuit breaker, E-Frame, 35A, 1 pole, 277 VAC, 65 kA max, bolt on | Mayer Electric

Mayer Electric Supply . EGB14035

Gallery

Attributes

Brand name, Manufacturer name, ManufacturerMayer Electric Supply
DimensionUnitinch
Extra Product NameMini circuit breaker, E-Frame, 35A, 1 pole, 277 VAC, 65 kA max, bolt on | Mayer Electric
UPC785901335184
Weight2
WeightUnitlbs
Weight_AttribNet Weight
depth, length4.05
height5.66
height_AttribHeight
jsonUrlData/Product/SQUARE-D-NF-Panelboard-MCB-EGB14035-785901335184
jsonUrlData21b1c5395-accf-465b-90de-abd20062059e
length_AttribDepth
moq, multiple, tierMinQty1, Number Of Spaces Required, Number Of Spaces, Number Of Poles1
MPNEGB14035
qtyInStock0
SKUSQDEGB14035
tierPrice1230.95
width0.98
width_AttribWidth
Module TypeE-Frame
Range Of Product125 A Frame EDB-EGB-EJB
Trip Unit Rating1800-1800 A
Product Or Component Typeminiature circuit-breaker
Device Short NameEGB
Warranty18 months
Circuit Breaker ApplicationHACR rated || HID rated
Height5.66 in
Mounting Modebolt-on
Holding Current630 A
Tightening Torque3.9-3.9 N.m 2.5-6 mm? (AWG 14...AWG 10) || 5.6-5.6 N.m 10-70 mm? (AWG 8...AWG 2/0)
Breaking Capacity CodeG
Product DestinationNF panelboard
Electrical Connectionlugs aluminium
Line Rated Current35 A
Protection Typeoverload || short-circuit
Local Signallingtrip indicator
Awg GaugeAWG 12...AWG 2/0 aluminium || AWG 14...AWG 2/0 copper
Width0.98 in
Depth4.05 in
Breaking Capacity35 kA 277 V AC || 35 kA 240 V AC || 65 kA 120 V AC || 35 kA 120/240 V AC
Net Weight2 lb(US)
Trip Unit Technologythermal-magnetic
[Ue] Rated Operational Voltage277 V AC
China Rohs RegulationProduct out of China RoHS scope. Substance declaration for your information.
Rohs Exemption Information, Mercury FreeYes
Eu Rohs DirectiveCompliant
Reach RegulationReference contains Substances of Very High Concern above the threshold
Product CertificationscULus
Ambient Air Temperature For Operation40 ?C

Distributor offers

SellerSKUMOQIn stockMultiplePrices
mayerelectric.comSQDEGB14035111 @ $230.95
