ForgeMaster Swivel Caster, 8" x 3" Duralast XC Polyurethane (70D) on Cast Iron Wheel

The Hamilton S-FM-83DT70 caster features an 8-inch diameter by 3-inch wide Duralast XC polyurethane wheel and precision tapered roller bearings with a -3/4 inch taper. It has a swivel design and a black finish.

HAMILTON ForgeMaster CastersA feature precision tapered thrust bearings placing them among the top double-ball race casters on the market today. -3/8" thick drop forged steel mounting plate. -5/16x2-1/2" plate steel legs are robotically welded inside and outside to forged steel horn base. Sturdy 1" diameter integrally forged kingpin with mounting plate. Main load bearing is 3-1/4" diameter CNC-machined raceway; secondary load bearing has 1" precision tapered thrust bearing that counteracts radial thrust. -3/4" diameter axle. Ball check type lubrication fittings in swivel assembly and wheel hub

Hamilton . S-FM-83DT70

Gallery

Attributes

Brand name, Manufacturer name, Manufacturer, Brand, Label, Man, Publisher, StudioHamilton
CategoryId, CategoryIdL46740
CategoryIdL1, CategoryIdL214394
CategoryIdL34473
CategoryL1Material Handling
CategoryL2Casters & Wheels
CategoryL3Casters
CategoryL4Plate Casters
DimensionUnitinch
GraingerSku, MPN, Part Number, Model, Keyword, ModelNumber, Model_number, PartNumber, Part_numberS-FM-83DT70
Extra Product NameForgeMaster Swivel Caster, 8" x 3" Duralast XC Polyurethane (70D) on Cast Iron Wheel
UPCNone
UnitOfMeasureEA
Weight30 30.0 30.00
WeightUnitlbs
cali_prop65_orglabel, cali_prop65_whtlabel, AdultProduct, Autographed, Memorabilia, TradeInEligibleFalse
countryOfOriginUS
extendedLead, Wheel Dia8
extendedQty-2
height, length, moq, multiple, tierMinQty1, width, Number of Wheels, Case, Item_package_quantity, NumberOfItems, Number_of_items, PackageQuantity1
jsonUrlData924526ffbdad25e5923b
qtyInStock0
qtyInStockOverrideDrop Ship
SKUG3721549
tierPrice1332.00
urlhttps://www.zoro.com/hamilton-forgemaster-swivel-caster-8-x-3-duralast-xc-polyurethane-70d-on-cast-iron-wheel-s-fm-83dt70/i/G3721549/
Product Group, WebsiteDisplayGroupNameHome Improvement
Wheel Width3
Mounting Bolt Dia0.5
Plate Size4 1/2 x 6 1/2
Mounting Height10.25
Caster Wheel ShapeStandard
Caster Wheel/Tread MaterialPolyurethane
Load Rating2400
Caster Plate Hole PatternA
Replacement WheelW-830-DT70-3/4
ItemSwivel Caster
Thread Guards, Non-MarkingNo
Caster Wheel Bearings, DisplayNameTapered
Caster Core MaterialCast iron
Frame FinishPowder Coat
Caster Frame MaterialForged Steel
Inside Bolt Hole Spacing2 7/16 x 4 15/16
StandardsICWM
Core ColorGray
Caster Temp Range-50 to 200 deg(F)
Outside Bolt Hole Spacing3 3/8 x 5 1/4
SeriesForgeMaster?
ASIN, AsinB00JR1HA7E
BindingMisc.
Bullet_point-3/4" Precision Tapered Roller Bearings Capacity: 2200 lbs. Overall Height: 10.25" Wheel Dia.xW: 8x3" Wheel Type: Black Polyurethane
CatIndustrial & Scientific
CatId16310091
CatTree16310091 16310161 16310181 16410991 16411251
ClassificationId16411311
ColorRed red
FeatureWheel Type: Black Polyurethane
Height10.25 1000 3.0 3.00 500 75
ItemClassificationBASE_PRODUCT
ItemName, Item_name, TitleHamilton Forgemaster Casters - 8"Dia.X3"W Duralast Xc Polyurethane Wheel - -3/4" Precision Tapered Roller Bearings - Swivel - Black
Item_display_weight, Item_package_weight, Item_weight30.0
Item_type_keywordtapered-roller-bearings
Length0.0 0.00 10.25 8.0
Linkhttps://m.media-amazon.com/images/I/41Jmb+NS5KL._SL75_.jpg https://m.media-amazon.com/images/I/41Jmb+NS5KL.jpg https://m.media-amazon.com/images/I/61J2R2SuSkL.jpg
Measurement_systemInch
ProductGroupBISS Basic Home Improvement
ProductTypeTOOLS
ProductTypeNameINDUSTRIAL_CASTERS TOOLS
Product_descriptionHAMILTON ForgeMaster CastersA feature precision tapered thrust bearings placing them among the top double-ball race casters on the market today. -3/8" thick drop forged steel mounting plate. -5/16x2-1/2" plate steel legs are robotically welded inside and outside to forged steel horn base. Sturdy 1" diameter integrally forged kingpin with mounting plate. Main load bearing is 3-1/4" diameter CNC-machined raceway; secondary load bearing has 1" precision tapered thrust bearing that counteracts radial thrust. -3/4" diameter axle. Ball check type lubrication fittings in swivel assembly and wheel hubs.
Product_site_launch_date2014-04-07T00:00:00.000-07:00
URLhttps://m.media-amazon.com/images/I/41Jmb+NS5KL._SL75_.jpg
Unitinches pounds
Unitsinches pixels pounds
VariantMAIN
WebsiteDisplayGrouphome_improvement_display_on_website
Width0.0 0.00 1000 3.0 500 75 8.0 8.00

Distributor offers

SellerSKUMOQIn stockMultiplePrices
ZoroG3721549111 @ $332.00
motionindustries.com05866914111 @ $492.78
AmazonSCB00JR1HA7E1-211 @ $325.15
National Supply Network175720211
ZoroG3284429111 @ $273.93

Related on Amazon

As an Amazon Associate, we earn from qualifying purchases. (paid link) CERTAIN CONTENT THAT APPEARS ON THIS SITE COMES FROM AMAZON. THIS CONTENT IS PROVIDED 'AS IS' AND IS SUBJECT TO CHANGE OR REMOVAL AT ANY TIME.

Hamilton Forgemaster Casters - 8"Dia.X3"W Duralast Xc Polyurethane Wheel - -3/4" Precision Tapered Roller Bearings - Swivel - Black
Brand: Hamilton
HAMILTON ForgeMaster CastersA feature precision tapered thrust bearings placing them among the top double-ball race casters on the market today. -3/8" thick drop forged steel mounting plate. -5/16x2-1/2" plate steel legs are robotically welded inside and outside to forged steel horn base. Sturdy 1" diameter integrally forged kingpin with mounting plate. Main load bearing is 3-1/4" diameter CNC-machined raceway; secondary load bearing has 1" precision tapered thrust bearing that counteracts radial thrust. -3/4" diameter axle. Ball check type lubrication fittings in swivel assembly and wheel hubs.
Details
  • Wheel Type: Black Polyurethane
  • Wheel Dia.xW: 8x3"
  • Capacity: 2200 lbs.
  • Overall Height: 10.25"
  • -3/4" Precision Tapered Roller Bearings
Listing
BindingMisc.
Product groupHome Improvement
Product typeTOOLS
ModelS-FM-83DT70
Part numberS-FM-83DT70
Items per pack1
LabelHamilton
ManufacturerHamilton
Catalog
FeatureWheel Type: Black Polyurethane
CategoryIndustrial & Scientific
MPNS-FM-83DT70
Product groupHome Improvement
Product typeTOOLS
ManufacturerHamilton
