YDT0420-4BP 1-1/2" x 7" Paper Cone Full-Range Speaker 16 Ohm

YDT0420-4BP 1-1/2" x 7" Paper Cone Full-Range Speaker 16 Ohm. Part Number: 289-2128 by Factory Buyouts.

Factory Buyouts . YDT0420-4BP

Gallery

Attributes

Brand name, Manufacturer name, Manufacturer, BrandFactory Buyouts
DimensionUnitinch
Extra Product NameYDT0420-4BP 1-1/2" x 7" Paper Cone Full-Range Speaker 16 Ohm
UPC848864047867
Weight0.35
WeightUnitlbs
depth, length1.93
diameter, height, width2.25
height_Attrib, width_AttribNominal Diameter
length_AttribDepth
moq, multiple1
MPN, ModelYDT0420-4BP
qtyInStock18079
SKU, Part Number289-2128
snippetYDT0420-4BP 1-1/2" x 7" Paper Cone Full-Range Speaker 16 Ohm. Part Number: 289-2128 by Factory Buyouts.
Unit of MeasureEach
Nominal Diameter2-1/4 x 6-1/4"
Power Handling (RMS)10 Watts
Power Handling (MAX)20 Watts
Impedance16?
Frequency Response200 to 12,000Hz
Sensitivity78dB 2.83V/1m
Voice Coil Diameter0.6"
Resonant Frequency (Fs)195.8Hz
DC Resistance (Re)16.11?
Voice Coil Inductance (Le)0.3305mH
Mechanical Q (Qms)4.729
Electromagnetic Q (Qes)7.548
Total Q (Qts)2.908
Compliance Equivalent Volume (Vas)0.01285ft?
Diaphragm Mass Inc Airload (Mms)2.558g
Cone Material, Voice Coil FormerPaper
Surround MaterialFoam
Basket / Frame MaterialPolymer
Magnet MaterialFerrite
Overall Outside Diameter1.6 x 8.56"
Baffle Cutout Diameter1.3 x 6.81"
Depth1.93"
# Mounting Holes4
