Baldor . VXM18542T

Gallery

Attributes

Brand name, Manufacturer name, ManufacturerBaldor
CategoryL1Electric Motors
CategoryL2AC Motors
CategoryL3AC Explosion Proof/Hazardous Location Motors
DimensionUnitinch
Extra Product NameBaldor VXM18542T 5/3HP 1750/1460RPM 3PH 60/50HZ 184TC Motor - MROSupply.com
diameter, height, width1.125
height_Attrib, width_AttribShaft Diameter
length20.36
length_AttribOverall Length
moq, multiple1
MPNVXM18542T
qtyInStock0
SKU6157862
snippetShop Baldor VXM18542T and trust MRO to be your reliable Baldor supplier to experience the difference that quality and expertise can make. Trusted since 1898. Fast, Free Shipping.
Frame184TC
EnclosureXPFC
Power factor74
Product familyGeneral Purpose
Shaft rotationReversible
Pull-up torque35.75 lb-ft
Lifting lugsNo lifting lugs
Synchronous speed @ frequency1800 RPM @ 60 HZ
Output @ frequency3.000 HP @ 50 HZ
Motor lead terminationFlying leads
Agency approvalsCSA EEV
XP class and groupCLI GP D; CLII GP F,G
Shaft ground indicatorNo shaft grounding
Inverter codeInverter duty
Locked bearing indicatorLocked bearing
Insulation classF
Mounting arrangementF1
Start configurationDOL
Starting current57.03 A
No-load current0 A
Break-down torque65.1 lb-ft
Thermal device - windingNormally closed thermostat
Frequency50.00 Hz
Pulley face codeC-face
Motor letter typeThree phase
Overall Length20.36 in
Phase3
Locked-rotor torque43.59 lb-ft
Constant torque speed range30
Current @ voltage6.800 A @ 460.0 V
Starting methodDirect on line
XP temp codeT3C
Shaft Diameter1.125 in
Heater indicatorNo heater
Motor standardsNEMA
Temp rise @ rated load42? C
Auxillary boxNo auxillary box
Electrically isolated bearingNot electrically isolated
Drip coverNo drip cover
Voltage @ frequency380.0 V @ 50 HZ
Duty ratingCONT
Frame materialSteel
Design codeA
Bearing grease typePolyrex EM (-20F +300F)
Service factor1.00
Number of poles4
Feedback deviceNo feedback
Efficiency @ 100% load89.5 %
XP divisionDivision I
High voltage full load amps5.6 a
Full load torque0 lb-ft
Speed codeSingle speed
KVA codeL
Line-line res @ 25? C1.91 Ohms A Ph / 0 Ohms B Ph
Max Speed2700 RPM
Vibration sensor indicatorNo vibration sensor
Motor type3646M
Speed1750 RPM
Base indicatorNo mounting
Ambient temperature (?C)40
