Baldor CXM18522T 5 3HP 3450 2900RPM 3PH 60/50HZ 184TC Motor

Shop Baldor CXM18522T and trust MRO to be your reliable Baldor supplier to experience the difference that quality and expertise can make. Trusted since 1898. Fast, Free Shipping.

Baldor . CXM18522T

Gallery

Attributes

Brand name, Manufacturer name, ManufacturerBaldor
CategoryL1Electric Motors
CategoryL2AC Motors
CategoryL3AC Explosion Proof/Hazardous Location Motors
DimensionUnitinch
Extra Product NameBaldor CXM18522T 5 3HP 3450 2900RPM 3PH 60/50HZ 184TC Motor
diameter, height, width1.125
height_Attrib, width_AttribShaft Diameter
length18.86
length_AttribOverall Length
moq, multiple1
MPNCXM18522T
qtyInStock0
SKU6101558
snippetShop Baldor CXM18522T and trust MRO to be your reliable Baldor supplier to experience the difference that quality and expertise can make. Trusted since 1898. Fast, Free Shipping.
Frame184TC
EnclosureXPFC
Power factor91
Product familyGeneral Purpose
Shaft rotationReversible
Pull-up torque25 lb-ft
Lifting lugsNo lifting lugs
Synchronous speed @ frequency3600 RPM @ 60 HZ
Output @ frequency3.000 HP @ 50 HZ
Shaft Diameter1.125 in
Agency approvalsCSA EEV
Heater indicatorNo heater
Shaft ground indicatorNo shaft grounding
Inverter codeInverter duty
Temp rise @ SF load58? C
Motor standardsNEMA
Full load torque0 lb-ft
Start configurationDOL
Starting current54.3 A
No-load current0 A
Break-down torque31.6 lb-ft
Thermal device - windingNormally closed thermostat
Constant torque speed range6
Pulley face codeC-face
Motor letter typeThree phase
Overall Length18.86 in
Phase3
Locked-rotor torque29.2 lb-ft
Current @ voltage8.800 A @ 190.0 V
Starting methodDirect on line
XP temp codeT3C
Base indicatorRigid
Motor lead terminationFlying leads
XP class and groupCLI GP D; CLII GP F,G
Insulation classF
Temp rise @ rated load48? C
Auxillary boxNo auxillary box
Electrically isolated bearingNot electrically isolated
Drip coverNo drip cover
Voltage @ frequency380.0 V @ 50 HZ
Duty ratingCONT
Locked bearing indicatorLocked bearing
Frame materialSteel
Design codeA
Efficiency @ 100% load88.5 %
Service factor1.15
Number of poles2
Feedback deviceNo feedback
KVA codeL
Bearing grease typePolyrex EM (-20F +300F)
High voltage full load amps4.4 a
Mounting arrangementF1
Speed codeSingle speed
Frequency50.00 Hz
Line-line res @ 25? C2.26 Ohms A Ph / 0 Ohms B Ph
Max Speed5400 rpm
Vibration sensor indicatorNo vibration sensor
Motor type3630M
Speed3450 rpm
XP divisionDivision I
Ambient temperature (?C)40

Distributor offers

SellerSKUMOQIn stockMultiplePrices
MRO Supply610155811
GalcoCXM18522T-BLDR111 @ $2750.19
emotorpro.comCXM18522T1-211 @ $2485.48
