NOSHOK . 25-1112-W200-A3P-1

Gallery

Attributes

Brand name, Manufacturer name, ManufacturerNOSHOK
Extra Product NameSunSource | 25-1112-W200-A3P-1 NOSHOK Industrial Hydraulics | SunSource.com
jsonUrlData18a4539b-c1ee-4abb-b9c1-ae640030d982
keywords1100 Series 0 to 200 inH 2 O Pressure Range Diaphragm Type Differential Pressure Gauge 25-1112-W200-A3P-1
moq, multiple, tierMinQty1, Syndication, Unit1
MPN, SKU25-1112-W200-A3P-1
qtyInStock0
snippet25-1112-W200-A3P-1 NOSHOK | Search our online catalog of Industrial Hydraulics. Start your quote online to connect with our team of technical experts for support.
tierPrice1662.38
1100 Series Diaphragm Type Differential Gauges Switch or Transmitter Type and HousingSingle Switch in NEMA 4x Enclosure4-20 mA Transmitter in NEMA 4x Enclosure
Alternating Current (AC) Voltage, Direct Current (DC) Voltage125
Ambient Temperature Range (4-20 mA Transmitter Option)-20 to 150
Ambient Temperature Range (Switch Option), Media Temperature Range (Switch Option)-40 to 200
ApplicationBack flow testingHeat exchangersFilter monitoringFlow indicationLevel indication
Bezel Material, MaterialEngineered Plastic
Category1100 Series Diaphragm Type Differential Pressure Gauges
Connection LocationBack
Connection Size1/4
Connection TypeFemale National Pipe Thread (FNPT)
Current Rating0.25
Dial/Display SizeAluminum, white background with black scale.
Full Scale on Rising Pressure Accuracy ()3/2/3
Gauge Size2-1/2|6
Lens/Display MaterialShatter-Resistant Acrylic
Measuring Element316 Stainless Steel and Ceramic Magnet
MovementMagnetic
NoteSPDT, 3W, 0.25 Amp, 125 Vac/Vdc (standard) (switch adjustable range of 15-95%). Other options available, consult factory.
Operating Temperature [Max]93
Operating Temperature [Min]-40
Options and Accessories(2) 1/4-20 Mounting Holes (MH)Pipe Mounting Kit, Steel (MK5-CS)Pipe Mounting Kit, Stainless steel (MK5-SS)Reversed Ports (RP)Stainless Steel Tagging (ST)Wall Mounting Kit (WMK)
O-Ring and Diaphragm MaterialsNitrile Rubber (NBR)
PointerBalanced Aluminum, Black Finish
Power Rating3
Pressure Range0 to 200
SchemaID101737
Sensor Housing MaterialsBlack Anodized Aluminum
Series1000
Switch RatingSingle Pole Double Throw (SPDT)
TypeDifferential Pressure Gauge
Working Static Pressure - Aluminum and Stainless Steel [Max]3,000
Working Static Pressure - Brass [Max]1,500
Price:$662.38

Distributor offers

SellerSKUMOQIn stockMultiplePrices
sun-source.com25-1112-W200-A3P-1111 @ $662.38
