U009-0034 | Thermostat | FanCoil | Commercial | PIR | 2 Fltg Cntcts | Aux Out | BAC | Veris (OBSOLETE)

Thermostat Power Requirements 19-30 VAC 50 or 60 Hz; 2 VA Class 2Operating Conditions 0° to 50°C (32° to 122°F); 0% to 95% R.H. non-condensingStorage Conditions -30° to 50°C (-22° to 122°F); 0% to 95% R.H. non-condensingTemperature Sensor Local 10 K NTC thermistorResolution ± 0.1°C (± 0.2°F)Control Accuracy Temp: ±0.5°C (±0.9°F ) @ 21°C (70°F) typical calibrated; Humidity: ±3% RH from 20 to 70% RH at 21°C (70°F)Occupied and Unoccupied Setpoint Range Cooling 12.0° to 37.5°C (54° to 100°F)Occupied and Unoccupied Setpoint Range Heating 4.5° to 32°C (40° to 90°F)Room and Outdoor Air Temperature Display -40° to 50°C (-40° to 122°F)Proportional Band for Room Temperature Range Control Cooling & Heating: 1.8°C (3.2°F )Binary Inputs Dry contact across terminal BI1 BI2 & UI3 to ScomOutputs Rating Triac output: 30 VAC 1 Amp max. 3 Amp in-rush; Analog: 0 to 10 VDC into 2k? resistance min.Economizer Analog Output Rating 0 to 10 VDC into 2k? resistance min.Economizer Analog Output Accuracy ±3% typicalWire Gauge 18 gauge maximum 22 gauge recommendedDimensions 4.94 x 3.38 x 1.13Approximate Shipping Weight 0.75 lb (0.34 kg)Agency Approvals:UL 873 (US) and CSA C22.2 No. 24 (Canada) File E27734 with CCN XAPX (US) and XAPX7 (Canada)FCC Compliant to CFR 47 Part 15 Subpart B Class A (US)Industry Canada ICES-003 (Canada)CE EMC Directive 89/336/EEC (Europe Union)C-Tick AS/NZS CISPR 22 Compliant (Australia / New Zealand) Supplier Code Number N10696
