Limit switch, 9007, 9007C 1 NO/NC, rotary head, CW+CCW, maintained | Mayer Electric

Mayer Electric Supply . 9007C54CY1901

Gallery

Attributes

Brand name, Manufacturer name, ManufacturerMayer Electric Supply
DimensionUnitinch
Extra Product NameLimit switch, 9007, 9007C 1 NO/NC, rotary head, CW+CCW, maintained | Mayer Electric
UPC785901479420
Weight1.25
WeightUnitlbs
Weight_AttribNet Weight
depth, length2.5
height8.04
height_AttribHeight
jsonUrlData/Product/SQUARE-D-9007C-limit-switch-1-NO-NC-rotary-head-CWCCW-maintained-785901479420
jsonUrlData2f8908e2e-5fa5-4bcf-9d8d-abd200617cdc
length_AttribDepth
moq, multiple, tierMinQty1, Sale Per Indivisible Quantity, Number Of Poles1
MPN9007C54CY1901
qtyInStock0
SKUSQD9007C54CY1901
tierPrice1451.36
width1.55
width_AttribWidth
Switch ActuationCW and CCW || from left and right
Type Of Approachlateral approach, 1 direction programmable
Series Nameheavy duty
Contacts Type And CompositionNC-NO
Movement Of Operating Headrotary
Range Of Product9007
Body Typeplug-in
Positive Opening, Local Signallingwithout
Electrical Connectionmale connector 7/8" - 16 UN - 2 A mini connector, 5 pins
Contact Operationsnap action
Product Specific Applicationstandard box
Fixing Modeby the body
Product Or Component Typelimit switch
Materialmetal
Device Short Name9007C
Type Of Operatorzinc stay put without operating lever -)9007C lever
Head Typerotary head
Warranty18 months
Maximum Displacement Angle90 ?
Height4.02-4.02 in
Terminals Description Iso N?1(1-2)NC || (3-4)NO
[Ui] Rated Insulation Voltage600 V 3)UL 508 contact block || 600 V 3)CSA C22.2 No 14 contact block
Tripping Angle45 ?
Short-Circuit Protection10 A CC non-time delay
[Ie] Rated Operational Current0.55 A 120 V DC || 0.27 A 240 V DC || 3 A 240 V AC NEMA || 6 A 120 V AC NEMA
Contacts Materialsilver contacts
Mechanical Durability10000000 cycles
Maximum Actuation Speed90 ft/min with 45? cam angle, levers only || 130 ft/min with 30? cam angle, levers only
Body Material, Head Materialzinc
[Ithe] Conventional Enclosed Thermal Current6 A
Contact FormForm Z
Switch FunctionSPDT-DB
[Uimp] Rated Impulse Withstand Voltage2.5 kV AC 1 min CE || 2.2 kV AC 1 min UL || 2.64 kV AC 1 s CSA
Width1.55 in
Depth2.5 in
Minimum Torque For Tripping3 lbf.in
Electrical Durability1000000 cycles
Net Weight1.25 lb(US)
Repeat Accuracy+/- 0.002 in linear travel of cam
Environmental DisclosureENVPEP111160EN
Eu Rohs DirectiveNot applicable, out of EU RoHS legal scope
Reach RegulationReference contains Substances of Very High Concern above the threshold
Ambient Air Temperature For Storage-20-185 ?F
Environmental Characteristicstandard environment
Nema Degree Of ProtectionNEMA 1 Nema type 250 || NEMA 2 Nema type 250 || NEMA 4 Nema type 250 || NEMA 6 Nema type 250 || NEMA 6P Nema type 250 || NEMA 12 Nema type 250 || NEMA 13 Nema type 250
Ambient Air Temperature For Operation-20-185 ?F standard environment
Electrical Shock Protection Classclass 0 IEC 61140
Shock Resistance60 gn 9 ms IEC 60068-2-27
Vibration Resistance25 gn 10-150 Hz)IEC 60068-2-6
Protective Treatmentepoxy powder coat
Ip Degree Of ProtectionIP67 conforming to IEC 60529

Distributor offers

SellerSKUMOQIn stockMultiplePrices
mayerelectric.comSQD9007C54CY1901111 @ $451.36
