1790315 Phoenix Contact | Connectors, Interconnects | DigiKey
PCB Plug Push-In 3.5mm 16AWG 160V 8A 4 Position Combicon Control Series
Gallery
Attributes
| Brand name, Manufacturer name, Manufacturer, Mfr | Phoenix Contact |
|---|---|
| Extra Product Name | 1790315 Phoenix Contact | Connectors, Interconnects | DigiKey |
| atoms, minimum, moq, multiple | 1 |
| MPN | 1790315 |
| qtyInStock | 433 |
| SKU | 277-10999-ND |
| Part Status | Active |
| Type | Plug, Female Sockets |
| Number of Positions | 8 |
| Positions Per Level | 4 |
| Number of Levels | 2 |
| Pitch | 0.138" (3.50mm) |
| Header Orientation, Operating Temperature, Ingress Protection, Screw Size, Torque - Screw, Contact Material, Contact Tail Length | - |
| Plug Wire Entry | 180? |
| Termination Style | Screwless - Push-In Spring |
| Mounting Type | Free Hanging (In-Line) |
| Current - IEC | 8A |
| Wire Gauge or Range - AWG | 16-24 AWG |
| Wire Gauge or Range - mm? | 0.2-1.5mm? |
| Color | Green |
| Contact Mating Finish | Tin |
| Features | Mating Flange |
| Material Flammability Rating | UL94 V-0 |
| Wire Strip Length | 10mm |
| Housing Material | Polyamide (PA), Nylon |
| Insulation Height | 0.522" (13.25mm) |
| Voltage - IEC | 250 V |
| Current - UL | 8 A |
| Voltage - UL | 150 V |
Distributor offers
| Seller | SKU | MOQ | In stock | Multiple | Prices |
|---|---|---|---|---|---|
| Digi-Key | 277-10999-ND | 1 | 433 | 1 | |
| Radwell | 1790315 | 50 | -2 | 50 | 1 @ $4.95 |
 Newark | 88W4760 | 1 | 26 | 1 | 1 @ $8.55, 10 @ $8.22, 50 @ $7.80, 100 @ $7.19, 250 @ $6.67, 500 @ $6.34, 1000 @ $5.98 |
| Allied Electronics | 71374003 | 50 | 50 | ||
| iodParts | 1790315 | 1 | 1 | ||
| Hotenda | H1591015 | 1 | 1 | 1 @ $5.96, 10 @ $5.80, 50 @ $5.42, 100 @ $4.99, 250 @ $4.61, 500 @ $4.39 | |
| 851-6297 | 1 | 1 | |||
| RS Online | 8818907 | 1 | 1 | ||
| Newark | 14X8477 | 50 | 50 | 1 @ $0.00 | |
| Digi-Key | 2743757 | 1 | 1 | 1 @ $6.82, 10 @ $6.64, 50 @ $6.20, 100 @ $5.71, 250 @ $5.27, 500 @ $5.04 | |
 Onlinecomponents.com | 1790315 | 4 | 100 | 1 | 4 @ $6.68, 100 @ $5.58, 1000 @ $4.56, 10000 @ $4.56 |
| Mouser | 651-1790315 | 1 | 417 | 1 | 1 @ $6.74, 10 @ $6.55, 100 @ $5.64, 1000 @ $4.66, 10000 @ $4.66 |
| RS Delivers | 881-8907 | 1 | 1 | ||
| us.rs-online.com | 71374003 | 50 | 50 | 50 @ $7.68 | |
| Airline Hydraulics | PHOENIX 1790315 | 1 | 1 | 1 @ $7.12 |
