OD172SAP-24HBXCIP69K Orion Fans | Fans, Thermal Management | DigiKey
Fan Tubeaxial 24VDC Rectangular/Rounded - 172mm L x 152mm H Ball 323.0 CFM (9.04m?/min) 2 Wire Leads
Gallery
Attributes
| Brand name, Manufacturer name, Manufacturer, Mfr | Orion Fans |
|---|---|
| CategoryL1, Category | Fans, Thermal Management |
| CategoryL2 | Fans |
| CategoryL3 | DC Brushless Fans (BLDC) |
| DimensionUnit | mm |
| Extra Product Name | OD172SAP-24HBXCIP69K Orion Fans | Fans, Thermal Management | DigiKey |
| Weight | 1.3 |
| WeightUnit | lbs |
| Weight_Attrib | Weight |
| atoms, moq, multiple, tierMinQty1 | 1 |
| extraShipping | 0 |
| MPN, Manufacturer Product Number | OD172SAP-24HBXCIP69K |
| packaging, Package | Bulk |
| qtyInStock | 76 |
| SKU | 13182666 |
| snippet, Detailed Description | Fan Tubeaxial 24VDC Rectangular/Rounded - 172mm L x 152mm H Ball 323.0 CFM (9.04m?/min) 2 Wire Leads |
| tierMinQty2 | 10 |
| tierMinQty3 | 25 |
| tierMinQty4 | 50 |
| tierMinQty5 | 100 |
| tierPrice1 | 103.96000 |
| tierPrice2 | 93.42900 |
| tierPrice3 | 92.11360 |
| tierPrice4 | 86.19200 |
| tierPrice5 | 84.21810 |
| width | 51.6 |
| width_Attrib | Width |
| Digi-Key Part Number | 1053-OD172SAP-24HBXCIP69K-ND |
| Description | FAN AXIAL 172X51.6MM 24VDC WIRE |
| Manufacturer Standard Lead Time | 19 Weeks |
| Series | OD172SAP XC |
| Product Status | Active |
| Voltage - Rated | 24VDC |
| Size / Dimension | Rectangular/Rounded - 172mm L x 152mm H |
| Width | 51.60mm |
| Air Flow | 323.0 CFM (9.04m?/min) |
| Static Pressure | 1.060 in H2O (264.0 Pa) |
| Bearing Type | Ball |
| Fan Type | Tubeaxial |
| Features | Auto Restart |
| Noise | 63.5dB |
| Power (Watts) | 50.4 W |
| RPM | 4400 RPM |
| Termination | 2 Wire Leads |
| Ingress Protection | IP69K - Dust Tight, Water Resistant, Waterproof |
| Operating Temperature | -4 ~ 149?F (-20 ~ 65?C) |
| Approval Agency | CE, cURus, TUV, UR |
| Current Rating (Amps) | 2.10A |
| Voltage Range | - |
| Material - Frame | Aluminum |
| Material - Blade | Polybutylene Terephthalate (PBT) |
| Lifetime @ Temp | 90000 Hrs @ 35?C |
| Base Product Number | OD172SAP |
Distributor offers
| Seller | SKU | MOQ | In stock | Multiple | Prices |
|---|---|---|---|---|---|
| 13182666 | 1 | 76 | 1 | 1 @ $103.96, 10 @ $93.43, 25 @ $92.11, 50 @ $86.19, 100 @ $84.22 | |
| Mouser | 670-OD172SA24HBXC69K | 1 | 9 | 1 | 1 @ $87.12, 10 @ $78.30, 100 @ $70.57, 1000 @ $70.57, 10000 @ $70.57 |
 Newark | 85AJ8898 | 1 | 1 | 1 @ $124.14, 1000 @ $113.80 | |
| 10142255 | 1 | 1 | 1 @ $103.40 |
