TOA F-1300WT Indoor White 70V Box Speaker

TOA F-1300WT Wide-Dispersion Two-way Speaker System, White, 30W Rated Power, 110º Horizontal x 100º Vertical Wide Directivity High-frequency Horn, Rear-mounted Rotary Switch The F-1300 Series Speaker are compact two-way speaker systems designed for high efficiency, wide range, and high power input handling capability. These speaker systems can be installed in a manner ideal for the location and intended application. Key Features - 8 Ohm 70V/100V Transformer - 110º horizontal x 100º vertical wide directivity high-frequency horn - Supplied bracket permits mounting to a wall, ceiling, or an optional speaker stand - Combined use of the supplied bracket and optional mounting bracket allows the speakers to be mounted in many different applications, including pole mounting, clusters, horizontal ceiling mounting, and partition board mounting - A rear-mounted rotary switch allows for speaker impedance selection of low impedance or high impedance Specifications - Enclosure: Bass-reflex type - Rated Input: 30W (high impedance) - Power Handling Capacity: Continuous pink noise: 50W (low impedance)/Continuous program: 150W (low impedance) - Rated Impedance: 8 Ω/100V line: 330 Ω (30W), 1 kΩ (10W), 3.3 kΩ (3W), 10 kΩ (1W)/70V line: 170 Ω (30W), 330 Ω (15W), 1 kΩ (5W), 3.3 kΩ (1.5W), 10 kΩ (0.5W) - Sensitivity: 90dB (1W, 1m) at installation in 1/2 free sound field - Frequency Response: 80Hz - 20kHz, -10 dB at installation in 1/2 free sound field - Crossover Frequency: 2kHz - Directivity Angle: Horizontal: 110°, Vertical: 100° - Speaker Component: Low frequency: 13cm (5") cone-type/High frequency: 25mm (1") dome tweeter - Input Terminal: Push-in terminal - Dimensions: 162 (W) x 250 (H) x 161 (D) mm (6.38" x 9.84" x 6.34") - Weight: 3.6 kg (7.94 lb) (including the supplied brackets)
