OD8032-48HB Orion Fans | Fans, Thermal Management | DigiKey
Fan Tubeaxial 48VDC Square - 80.5mm L x 80.5mm H Ball 50.0 CFM (1.40m?/min) 2 Wire Leads
Gallery
Attributes
| Brand name, Manufacturer name, Manufacturer, Mfr | Orion Fans |
|---|---|
| Extra Product Name | OD8032-48HB Orion Fans | Fans, Thermal Management | DigiKey |
| atoms, minimum, moq, multiple | 1 |
| MPN | OD8032-48HB |
| qtyInStock | 195 |
| SKU | 1053-1268-ND |
| Part Status | Active |
| Voltage - Rated | 48VDC |
| Size / Dimension | Square - 80.5mm L x 80.5mm H |
| Width | 32.00mm |
| Air Flow | 50.0 CFM (1.40m?/min) |
| Static Pressure | 0.430 in H2O (107.1 Pa) |
| Bearing Type | Ball |
| Fan Type | Tubeaxial |
| Features, Ingress Protection, Weight | - |
| Noise | 40.0dB |
| RPM | 3800 RPM |
| Termination | 2 Wire Leads |
| Operating Temperature | -4 ~ 176?F (-20 ~ 80?C) |
| Approval Agency | cURus, TUV |
| Current Rating (Amps) | 0.160A |
| Voltage Range | 24 ~ 56VDC |
| Material - Frame, Material - Blade | Polybutylene Terephthalate (PBT), Fiberglass Reinforced |
| Lifetime @ Temp | 60000 Hrs @ 40?C |
Distributor offers
| Seller | SKU | MOQ | In stock | Multiple | Prices |
|---|---|---|---|---|---|
| 1053-1268-ND | 1 | 195 | 1 | ||
| Onlinecomponents.com | OD8032-48HB | 1 | 1 | 1 @ $12.56, 2 @ $11.93, 26 @ $11.34, 101 @ $10.77, 501 @ $10.39, 1001 @ $9.87 | |
 arcade-electronics.com | ORI-OD8032-48HB | 1 | -2 | 1 | 1 @ $15.97 |
| Hotenda | H1901440 | 1 | 85 | 1 | 1 @ $15.52, 10 @ $14.78, 25 @ $13.86, 100 @ $12.29, 250 @ $11.55, 500 @ $11.32 |
| RS Delivers | 2508498950 | 1 | 1 | ||
 Carlton Bates Company | 40308486216 | 1 | 1 | 1 @ $15.47 | |
| Future Electronics | 8046424 | 20 | 20 | 20 @ $20.44, 5 @ $18.64, 10 @ $17.92, 25 @ $17.01, 50 @ $16.34 | |
| AmazonSC | B00Q7VNLCA | 1 | 1 | ||
 Newark | 89AH2624 | 1 | 13 | 1 | 1 @ $15.97, 5 @ $15.97, 10 @ $15.97, 25 @ $15.97, 50 @ $14.83, 100 @ $13.84 |
| 2621173 | 1 | 88 | 1 | 1 @ $21.54, 10 @ $19.67, 25 @ $18.93, 50 @ $17.68, 100 @ $16.31, 250 @ $16.06, 500 @ $15.94 | |
 Newark | 51AK1756 | 1 | 1 | 1 @ $24.53, 25 @ $22.68, 50 @ $21.25, 100 @ $20.64, 250 @ $20.03 | |
 Galco | OD8032-48HB-ORIN | 1 | 1 | 1 @ $20.35 | |
| 10142032 | 1 | 1 | 1 @ $17.30 | ||
| us.rs-online.com | 70103773 | 1 | 10 | 1 | 1 @ $21.80, 10 @ $19.91, 25 @ $19.15, 50 @ $17.89, 100 @ $16.51, 250 @ $16.25 |
