Tygon

.

Tygon . AZY02029

Gallery

Attributes

Brand name, Manufacturer name, Manufacturer, Extra Product NameTygon
DimensionUnitinch
GraingerSku2DCG5
UPCNone
UnitOfMeasureEA
Weight11.1
WeightUnitlbs
cali_prop65_orglabel, cali_prop65_whtlabelFalse
countryOfOriginUS
height4.5
jsonUrlData924526ffbdad25e5923b
length21.5
moq, multiple, tierMinQty11
MPNAZY02029
qtyInStock6
qtyInStockOverride-2
SKUG1516961
tierPrice1348.00
urlhttps://www.zoro.com/tygon-tubing-braided-poly-38-in-clear-azy02029/i/G1516961/
width20.5
Tube Material, Tubing MaterialPolyurethane
Tube HardnessShore A: 85
Inside Dia, Inside Diameter3/8 in
Outside Dia, Outside Diameter5/8 in
Wall Thickness1/8 in
Max Pressure205 psi
Tube Length, Overall Length100 ft
Tube Color, Color, Jacket Color, ClarityClear
Vacuum Rating, Maximum Vacuum Pressure29.9 in Hg
TypeTygothane(R), Braided
ItemTubing
StandardsFDA 21CFR, Reach Compliant
Temp Range-100 Degrees to 175 Degrees F
Burst Pressure820 psi
Tubing ReinforcementSpiral Yarn
Material BrandTYGON Versilon C-544-A IB
For Potable Water UseYes
Material Trade NameVersilon
Bend Radius1 1/2 in
Tubing HardnessFirm (A85-95)
Maximum Operating Temperature180 Degrees F
Jacket MaterialTPU
Does Not ContainBPA, Phthalates above limits in REACH, RoHS, CA Prop 65, Latex, Substances on REACH or RoHS above limit
Tradename MaterialVersilon C-544-A IB
Stripe ColorNo Stripe
Minimum Operating Temperature-100 Degrees F
Brand MaterialVersilon C-544-A-IB
Petroleum Product CompatibilityFuel Oil, Gasoline, Automotive, Kerosene, Lubricants, Mineral Oil, Turpentine
Vacuum RatedVacuum Rated
FlexibilityFlexible
Peristaltic Pump Compatible, AutoclavableNo
For EnvironmentExtreme Temperature, Oily
Beverage, Food, and Water Compatibility, Food and Beverage CompatibilityBeer, Citric Acid, Dairy, Distilled Water, Glycerin, Linseed Oil, Milk, Non-Potable Water, Oils and Fats, Orange Juice, Potable Water, Salt Water, Soft Drinks, Vinegar
Industry ApplicationPneumatics
Tube FormCoil
ReinforcementYarn Reinforced
Material Trade NumberC-544-A IB
Fitting CompatibilityBarbed
PEX TypeNot Applicable
Elongation400%
Resistance PropertiesAbrasion Resistant, Fuel Resistant, Grease Resistant, Oil Resistant, Tear Resistant, Temperature Resistant
For Fluid TypeFuel, Oil
HardnessShore A 85
Maximum Operating Pressure205 psi @ 73 Degrees F
System of MeasurementInch
Country of Origin (subject to change)United States

Distributor offers

SellerSKUMOQIn stockMultiplePrices
ZoroG15169611611 @ $348.00
simsupply.comZO-G15169611311 @ $470.77
Grainger2DCG511
