HBM PWS-60kg Stainless Steel Single Point Load Cell, NTEP - Scales Plus

HBM . PWS-60KG

Gallery

Attributes

Brand name, Manufacturer name, ManufacturerHBM
DimensionUnitmm
Extra Product NameHBM PWS-60kg Stainless Steel Single Point Load Cell, NTEP - Scales Plus
height23.9
height_AttribHeight
length139.7
length_AttribLength
moq, multiple, tierMinQty11
MPNPWS-60KG
qtyInStock0
SKU36189
tierPrice1367.65
width30.2
width_AttribWidth
ModelPWS-60kg
ApprovalsFM, NTEP
CertificationNTEP Certified 1:3000 Class III
Capacity Rating60 kg
Safe Overload150% capacity
Length139.7 mm
Height23.9 mm
Width30.2 mm
Thredding1/4-20 UNC
Construction / FinishStainless steel
Cable Color CodeGreen = + Excitation, Black = - Excitation, Red = + Signal, White = - Signal, Yellow = Shield
Rated Excitation5-10 VDC (15 V maximum)
Full Scale Output2 mV/V
Output Resistance359 (? 10) ohm
Input Resistance390 (? 15) ohm
Insulation Resistance5,000 megohms
Compensated Temperature Range14 ?F to 104 ?F (-10 ?C to 40 ?C)
Operating Temperature Range0 ?F to 150 ?F (-18 ?C to 65 ?C)
Seal TypeEnvironmentally sealed IP67
Combined Error0.03 % full scale
Cable Length10 ft
Cable Diameter0.190 PVC jacket

Distributor offers

SellerSKUMOQIn stockMultiplePrices
scalesplus.com36189111 @ $367.65
