STMicroelectronics X0202NN 5BA4 | Thyristor; 800V; Ifmax: 1.25A; 0.8A; Igt: 200uA; SOT223; SM

STMicroelectronics . X0202NN 5BA4

Attributes

Brand name, Manufacturer name, Mfr, BrandSTMicroelectronics
ManufacturerSTMicroelectronics ST MICROELECTRONICS STMICROELECTRONICS Stmicroelectronics
Extra Product NameX0202NN 5BA4 STMicroelectronics | Discrete Semiconductor Products | DigiKey
atoms, moq, multiple, tierMinQty1, Item_package_quantity1
extraShipping0
MPN, Part Number, Model, ModelNumber, Model_number, Mpns, PartNumber, Part_numberX0202NN 5BA4
qtyInStock5061
SKU1884979
tierMinQty210
tierMinQty325
tierMinQty4100
tierMinQty5500
tierPrice11.07000
tierPrice20.95400
tierPrice30.90520
tierPrice40.74360
tierPrice50.61428
CategoryDiscrete Semiconductor Products
Series-
PackageTape & Reel (TR)
Part StatusActive
Current - Non Rep Surge 50, 60Hz (Itsm)22.5A, 25A
SCR TypeSensitive Gate
Operating Temperature-40?C ~ 125?C
Mounting TypeSurface Mount
Package / CaseTO-261-4, TO-261AA
Supplier Device PackageSOT-223
Voltage - Off State800 V
Voltage - Gate Trigger (Vgt) (Max)800 mV
Current - Gate Trigger (Igt) (Max)200 ?A
Voltage - On State (Vtm) (Max)1.45 V
Current - On State (It (AV)) (Max)800 mA
Current - On State (It (RMS)) (Max)1.25 A
Current - Hold (Ih) (Max)5 mA
Current - Off State (Max)5 ?A
