AMERICAN ROTARY . AD05

VIT Generator | Full Current Latching Starter | 3 Phase Breaker and Receptacle Slots | MicroSmart Digital Industrial Programmable Controller | General Specifications: Single motor start max. (HP): 2.5 | CNC/VFD (HP): 2.5 | Resistive/Oven (amps): 7.5 | Rectified/Welder (amps): 7.5 | kW of Generator (based on FLA): 3.7 | Idler/Generator FLA: 14 | Frequency (Hz): 60 | Generator Type: GENTEC/Variable Impendence | Magnetic Starter: Included (remote start ready) | Panel Enclosure: NEMA 1 | Temperature Rating: 40 C Ambient | Wave Form: Pure Sinusoidal Analog | Phase Angle: 120 degrees | Efficency: 0.97 | Three Phase Output Specifications (continuous): Output Voltage: Equals input voltage | Voltage Tolerance: Meets IEEE Std 241-1990 utility | 3-Phase Output Configuration: 3-Wire Delta | Service Factor: 1.5 | Output Frequency (Hz): Input Frequency | Output Current (use for resistive & rectified loads, i.e. Welder, CNC, VFD, Power-supply)-amps @ 240V: 3-phase output current recommended for CNC, welder, VFD, voltage sensitive: 7 | Maximum Current for IEEE Standard Utility Line: 9 | Starting Motor loads (HP/kW): Maximum HP/kW Start (Moderate Load) Type 1: 4/3 | Maximum HP/kW Start (Hard Load) Type 2: 2.5/1.9 | Maximum HP/kW Start (High Inertia) Type 3: 2/1.5 | Maximum HP/kW Start (High Inertia)Type 3 w/ADX: 2.5/1.9 | Maximum HP/kW Total Motor Group Load: 7.5/5.6 | Maximum HP/kW (CNC or VFD) Type 4: 2.5/1.9 | Single Phase Input Specifications (continuous): Voltage Input: 208-250 | Input Frequency (Hz): 60 | (HP Load / 1-PH Amps): 1.5/6 | (HP Load / 1-PH Amps): 2.5/11 | (HP Load / 1-PH Amps): 4/20 | Power Consumption (kW): 0.08 | Cost to Run (@.10/kW/HP): $0.08/hr | Minimum Breaker Size: 2 x load current
