Hamilton

Hamilton . S-MDK-83HFSB-H4SL-HCB

Gallery

Attributes

Brand name, Manufacturer name, Manufacturer, Extra Product NameHamilton
DimensionUnitinch
GraingerSku55HA11
UnitOfMeasureEA
Weight80
WeightUnitlbs
cali_prop65_orglabel, cali_prop65_whtlabelFalse
countryOfOriginUS
extendedLead20
extendedQty-2
height6
jsonUrlData924526ffbdad25e5923b
length, width12
moq, multiple, tierMinQty1, Number of Wheels1
MPNS-MDK-83HFSB-H4SL-HCB
qtyInStock0
qtyInStockOverrideDrop Ship
SKUG9072224
tierPrice12742.93
urlhttps://www.zoro.com/hamilton-plate-caster-5500-lb-load-rating-s-mdk-83hfsb-h4sl-hcb/i/G9072224/
Caster Sub-TypeSwivel
Load Rating5500 lb
Wheel Dia8 in
Wheel Width, Overall Wheel Width3 in
Wheel Bearing TypePrecision Ball
Swivel Bearing Seal TypeOpen
Wheel/Tread Color, Core ColorSilver
Wheel TypeFlat-Free
Wheel Core MaterialForged Steel
Tire StyleTubeless
Frame FinishEnamel
Outside Bolt Hole Spacing, Inside Bolt Hole Spacing7 in x 7 in
NSF Listed, With Toe Plate, Leveling Caster, Includes Mounting Fasteners, Includes Thread Guards, Non-MarkingNo
Includes Spanner Bushing, ESD ConductiveYes
FeaturesDurable, High Heat, Quiet Operation, Reliable
Wheel/Tread Hardness RatingExtra Hard
Caster Product GroupKingpinless Caster with 4-Position Directional Lock and Brake
Load Rating Range3000 to 5999 lb
Swivel Raceway TypeSingle Ball
Swivel ConstructionKingpinless
Wheel/Tread Hardness179 BHN
Mounting Plate Size8 1/2 in x 8 1/2 in
Caster Brake TypeFace Contact Brake
Mounting Plate Thickness, Mounting Bolt Dia5/8 in
Brake LocationFace
Swivel Lead2 1/2 in
For Surface TypeConcrete
Caster Frame Material, Wheel/Tread MaterialSteel
Swivel Lock Type4-Position Swivel Lock
ItemHeat-Resistant Standard Plate Caster
SeriesMagmaMax
ApplicationAerospace Tooling, All Purpose Industrial/Commercial Casters, Automotive Assembly Lines, Body Dolly Carts, Chassis Rack Carts, Engine Dollies, Material Carts
StandardsICWM
TreadFlat
Wheel Bearing MaterialStainless Steel
Wheel Core TypeSolid
Operating Temperature Range-50 Degrees to 200 Degrees F
Tread ShapeStandard
Frame ConstructionForged
Frame ColorBlack
For Axle Dia1 1/4 in
Mounting Height11 in
Caster Mounting TypePlate
Mounting Plate Bolt Hole PatternD
Swivel Radius6 1/2 in
Number of Mounting Holes4
Country of Origin (subject to change)United States

Distributor offers

SellerSKUMOQIn stockMultiplePrices
ZoroG9072224111 @ $2742.93
Grainger55HA11111 @ $4075.97
