ACTi . V21
The
Gallery
Attributes
Distributor offers
| Seller | SKU | MOQ | In stock | Multiple | Prices |
|---|---|---|---|---|---|
| bhphotovideo.com | ACV21 | 1 | 1 | 1 @ $246.95 | |
 Zoro | G2020545 | 1 | 1 | 1 @ $245.74 | |
 Grainger | 45LM56 | 1 | 1 | 1 @ $495.00 | |
| V21 | 1 | -2 | 1 | 1 @ $283.09 | |
 surveillance-video.com | V21 | 1 | -2 | 1 | 1 @ $339.00 |
 Zoro | G2467925 | 1 | 1 | 1 @ $317.99 | |
| barcodegiant.com | ACT308218 | 1 | 1 | ||
| Graybar | 25763400 | 1 | 1 | 1 @ $387.75 | |
| ACI-V21 | 1 | -2 | 1 | 1 @ $283.09 | |
| V21 | 1 | -2 | 1 | 1 @ $298.60 | |
 networkcamerastore.com | ACI-V21 | 1 | -2 | 1 | 1 @ $342.46 |
Related on Amazon
As an Amazon Associate, we earn from qualifying purchases. (paid link) CERTAIN CONTENT THAT APPEARS ON THIS SITE COMES FROM AMAZON. THIS CONTENT IS PROVIDED 'AS IS' AND IS SUBJECT TO CHANGE OR REMOVAL AT ANY TIME.
Acti Video Encoder
Brand: ACTI
Details
- Machining
- Manufacturer: Acti
- Made in: Taiwan
Listing
| Binding | Misc. |
|---|---|
| Product group | BISS Basic |
| Product type | SAFETY_SUPPLY |
| Model | V21 |
| Part number | V21 |
| Items per pack | 1 |
| Label | ACTI |
| Manufacturer | ACTI |
ACTi V21 960 x 480pixels 30fps Video Servers/Encoder
Brand: ACTi
Listing
| Binding | Personal Computers |
|---|---|
| Product group | Personal Computer |
| Product type | PERSONAL_COMPUTER |
| Model | V21 |
| Part number | V21 |
| Label | ACTi |
| Manufacturer | ACTi |
ACTi V21 1-Channel 960H/D1 H.264 Video Encoder with, BNC Video Input, RJ-45 Video Output, Audio, MicroSDHC/MicroSDXC, RS-485, RS-422, DI/DO, PoE/DC12V
Brand: ACTi
ACTi V21 1-Channel 960H/D1 H.264 Video Encoder with, BNC Video Input, RJ-45 Video Output, Audio, MicroSDHC/MicroSDXC, RS-485, RS-422, DI/DO, PoE/DC12V Key Features Event trigger, response and notification Web Client, Mobile Client Specifications Maximum Number of Cameras: 1 Pan, Tilt or Zoom protocol: Pelco-D, Pelco-P V2, Dynacolor Compression: H.264 (Baseline/ Main/ High profile), MJPEG Multi-Streaming: Simultaneous dual streams Bit Rate: 28Kbps-6Mbps (per stream) Bit Rate Mode: Constant, Variable Image Enhancement: Brightness, Saturation, Contrast, Sharpness Privacy Mask: 4 configurable regions Text Overlay: Yes Image Orientation: Flip, Mirror Audio Type: 2-way, Line-in, Line-out Audio Compression: 8 kHz, Mono, PCM, 16 bit encoding, G.711 Ethernet Port: 1 x RJ-45 connector Mobile Client Program: Mobile device application (ACTi Mobile Client) supports Live View, PTZ Control, Supported device(s) iPhone, Android device Unified Solution: Fully compatible with ACTi cameras Software Development Kit: Yes GPS Position: Manual setting ONVIF Compliant: Yes, Profile S Web Browser: IE 11 Serial Port: 1, RS-485/RS-422, Terminal block Audio Interface: 1/1, Terminal block Analog Video Input: 1x CVBS, BNC connector Analog Video Output: 1x CVBS, BNC connector Digital Input/Output: 1/1 Power Source: DC 7-20V, PoE Class 3 (IEEE802.3af) Power Consumption: 3W (DC), 3.36W (PoE) Starting Temperature: -10°C~50°C Operating Temperature: -10°C~50°C Operating Humidity: 10%-85% RH Remote Access: Web Client, Mobile Client UPC: 888034004887 EAN: 4718201798546 Dimensions: 5.4"x1.4"x4.8") Weight: 0.977lb
Details
- Maximum Frame Rate vs. Resolution: 30 fps at 960 x 480, 25 fps at 960 x 576, 30 fps at 720 x 480, 25 fps at 720 x 576
- Server-based Analytics: Face Detection, Object Based Motion Detection, Tamper, People Counting, Object Line Crossing Detection, Object Enter Area Detection, Missing Object Detection, Unattended Object Detection, Crowd Detection, Vehicle Counting, Heat Map, Automatic License Plate Recognition, Vehicle Speed Detection
- Security: IP address filtering, HTTPS encryption, Password protected user level, IEEE 802.1X network access control, Anonymous login
- Event Trigger: Video motion detection (3 regions), External device through digital input, Sound detection, Video loss, Video Recovery, Scheduler, Storage removed, Failed to write storage, System is going to reboot, System booted successfully
- Event Response: Notify control center, Go to PTZ preset point or preset tour, Change camera settings, Command other devices, E-mail notification with snapshots, Save video or snapshot to local storage, Upload video or snapshot to FTP server, Activate external device through digital output, Change motion detection profile
ACTI V21
Brand: ACTi
Listing
| Binding | Electronics |
|---|---|
| Product group | CE |
| Product type | NETWORKING_DEVICE |
| Part number | V21 |
| Label | Acti |
| Manufacturer | Acti |
